DETAILED COOLING CAPACITIES
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh{
Total Sys-
tem
KW**
Capacity
MBtuh{
Total
System
KW**
Capacity
MBtuh{
Total
System
KW**
Capacity
MBtuh{
Total
System
KW**
Capacity
MBtuh{
Total
System
KW**
Capacity
MBtuh{
Total
System
KW**
Total Sens} Total Sens } Total Sens} Total Sens} Total Sens} Total Sens}
24ABR318(A,G)30 Outdoor Section With CAR**1814A** Indoor Section
525
72 20.98 11.15 1.15 20.00 10.79 1.30 19.13 10.46 1.48 18.43 10.20 1.72 17.93 10.02 2.02 17.49 9.86 2.32
67 18.66 13.55 1.16 17.75 13.18 1.30 16.93 12.84 1.47 16.28 12.58 1.71 15.78 12.37 1.99 15.27 12.17 2.26
62 16.83 15.95 1.16 16.03 15.54 1.29 15.34 15.16 1.46 14.81 14.81 1.69 14.41 14.41 1.97 14.01 14.01 2.22
57 16.56 16.56 1.16 15.89 15.89 1.29 15.30 15.30 1.46 14.81 14.81 1.69 14.41 14.41 1.97 14.01 14.01 2.22
600
72 21.43 11.76 1.17 20.42 11.38 1.32 19.51 11.05 1.50 18.78 10.79 1.74 18.27 10.60 2.04 17.84 10.45 2.36
67 19.08 14.50 1.18 18.14 14.12 1.32 17.30 13.78 1.50 16.63 13.50 1.73 16.12 13.30 2.02 15.62 13.10 2.30
62 17.40 17.15 1.18 16.64 16.64 1.32 16.01 16.01 1.49 15.50 15.50 1.72 15.10 15.10 2.01 14.69 14.69 2.27
57 17.35 17.35 1.18 16.65 16.65 1.32 16.02 16.02 1.49 15.50 15.50 1.72 15.10 15.10 2.01 14.69 14.69 2.27
675
72 21.78 12.32 1.20 20.73 11.94 1.34 19.79 11.60 1.53 19.04 11.34 1.77 18.52 11.15 2.08 17.45 10.78 1.65
67 19.41 15.40 1.20 18.45 15.01 1.34 17.59 14.66 1.52 16.90 14.38 1.76 16.39 14.17 2.05 15.90 13.97 2.34
62 18.01 18.01 1.20 17.27 17.27 1.34 16.61 16.61 1.52 16.08 16.08 1.75 15.67 15.67 2.04 15.26 15.26 2.32
57 18.02 18.02 1.20 17.28 17.28 1.34 16.61 16.61 1.52 16.08 16.08 1.75 15.67 15.67 2.04 15.26 15.26 2.32
Multipliers for Determining the Performance With Other Indoor Sections
Cooling Indoor
Model
Capacity Power Furnace Model
*CAR**1814A** 1.00 1.00
CAR**2414A** 1.02 1.02
CAR**2417A** 1.02 1.02
CNRF*2418A** 1.02 1.02
CNRH*2417A** 1.02 1.02
CNRV*1814A** 1.00 1.00
CNRV*2414A** 1.02 1.02
CNRV*2417A** 1.02 1.02
CSRH*2412A* * 1.02 1.02
FA4CN(F,C)018 1.01 1.01
FA4CN(F,C)024 1.01 1.01
FC4DNF018 1.02 0.98
FC4DNF024 1.03 0.98
FF1ENE018 1.01 1.01
FF1ENE024 1.02 1.02
FK4DNF001 1.01 0.97
FK4DNF002 1.03 0.98
Cooling Indoor
Model
Capacity Power Furnace Model
CAR**1814A** 0.98 0.94 58CV(A,X)070---12
CAR**2414A** 1.01 0.96 58CV(A,X)070---12
CNRH*2417A** 1.01 0.96 58CV(A,X)070---12
CNRV*1814A** 0.98 0.94 58CV(A,X)070---12
CNRV*2414A** 1.01 0.96 58CV(A,X)070---12
CSRH*2412A* * 1.01 0.96 58CV(A,X)070 ---12
CAR**2417A** 1.01 0.96 58CV(A,X)090---16
CNRH*2417A** 1.01 0.96 58CV(A,X)090---16
CNRV*2417A** 1.01 0.96 58CV(A,X)090---16
CSRH*2412A* * 1.01 0.96 58CV(A,X)090 ---16
CNRH*2417A** 1.01 0.96 58MVB040---14
CSRH*2412A* * 1.01 0.96 58MVB040---14
CAR**2417A** 1.01 0.96 58MVB060---14
CNRH*2417A** 1.01 0.96 58MVB060---14
CNRV*2417A** 1.01 0.96 58MVB060---14
CSRH*2412A* * 1.01 0.96 58MVB060---14
CNRH*2417A** 1.01 0.96 58MVB080---14
CSRH*2412A* * 1.01 0.96 58MVB080---14
