Carrier 25VNA Product Data

36
HEAT PUMP HEATING PERFORMANCE CONTINUED
25VNA060A**30 Outdoor Section With FE4ANB006 Indoor Section
HEATING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
*FE4ANB006 1.00 1.00
CAP**6021A** 1.00 1.05 58CV(A,X)110 ---20
CNPH*6024A** 1.00 1.04 58CV(A,X)110---20 CNPH*6124A** 0.99 1.03 58CV(A,X)110---20
CNPV*6024A** 1.03 1.08 58CV(A,X)110 ---20 CNPV*6124A** 1.02 1.05 58CV(A,X)110 ---20
CSPH*6012A** 1.00 1.03 58CV(A,X)110---20
CAP**6024A** 0.99 1.02 58CV(A,X)135 ---22 CAP**6025A** 0.99 1.02 58CV(A,X)135 ---22
CNPH*6024A** 0.99 1.02 58CV(A,X)135---22 CNPH*6124A** 0.99 1.02 58CV(A,X)135---22
CNPV*6024A** 1.01 1.04 58CV(A,X)135 ---22 CNPV*6124A** 1.00 1.01 58CV(A,X)135 ---22
CSPH*6012A** 0.99 1.01 58CV(A,X)135---22
CAP**6024A** 0.99 1.01 58CV(A,X)155 ---22 CAP**6025A** 0.99 1.01 58CV(A,X)155 ---22
CNPH*6024A** 0.99 1.01 58CV(A,X)155---22 CNPH*6124A** 0.98 1.00 58CV(A,X)155---22
CNPV*6024A** 1.00 1.02 58CV(A,X)155 ---22 CNPV*6124A** 1.00 0.99 58CV(A,X)155 ---22
CSPH*6012A** 0.99 1.00 58CV(A,X)155---22
CAP**6021A** 1.01 1.07 59*N*A080V21**20 CAP**6024A** 1.01 1.07 59*N*A080V21**20
CNPH*6024A** 1.03 1.08 59*N*A080V21**20
HEATING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CNPV*6024A** 1.03 1.08 59*N*A080V21**20
CSPH*6012A** 1.02 1.06 59*N*A080V21**20
CAP**6021A** 1.01 1.06 59*N*A100V21**22 CAP**6024A** 1.01 1.06 59*N*A100V21**22
CNPH*6024A** 1.04 1.08 59*N*A100V21**22
CNPV*6024A** 1.04 1.08 59*N*A100V21**22
CSPH*6012A** 1.02 1.05 59*N*A100V21**22
CAP**6024A** 1.03 1.09 59*N*A120V24**22 CAP**6025A** 1.00 1.07 59*N*A120V24**22
CNPH*6024A** 1.04 1.09 59*N*A120V24**22 CNPH*6124A** 0.99 1.06 59*N*A120V24**22
CNPV*6024A** 1.04 1.09 59*N*A120V24**22 CNPV*6124A** 1.01 1.05 59*N*A120V24**22
CSPH*6012A** 1.04 1.07 59*N*A120V24**22
CAP**6021A** 1.01 1.11 59MN7A060V21**20 CAP**6024A** 1.01 1.11 59MN7A060V21**20
CNPH*6024A** 1.02 1.10 59MN7A060V21**20
CNPV*6024A** 1.02 1.10 59MN7A060V21**20
CSPH*6012A** 1.02 1.10 59MN7A060V21**20
CAP**6021A** 1.01 1.09 58MV(B,C)080---20
CNPH*6024A** 1.01 1.09 58MV(B,C)080---20 CNPH*6124A** 1.00 1.07 58MV(B,C)080---20
CNPV*6024A** 1.00 1.08 58MV(B,C)080---20
HEATING INDOOR
MODEL
CAPACITY POWER FURNACE MODEL
CNPV*6124A** 1.04 1.09 58MV(B,C)080---20
CSPH*6012A** 1.01 1.08 58MV(B,C)080---20
CAP**6021A** 1.01 1.09 58MV(B,C)100---20
CNPH*6024A** 1.01 1.08 58MV(B,C)100---20 CNPH*6124A** 1.00 1.07 58MV(B,C)100---20
CNPV*6024A** 1.04 1.11 58MV(B,C)100---20 CNPV*6124A** 1.03 1.08 58MV(B,C)100---20
CSPH*6012A** 1.00 1.06 58MV(B,C)100---20
CAP**6024A** 1.00 1.05 58MV(B,C)120---20 CAP**6025A** 1.00 1.05 58MV(B,C)120---20
CNPH*6024A** 1.00 1.05 58MV(B,C)120---20 CNPH*6124A** 1.00 1.05 58MV(B,C)120---20
CNPV*6024A** 1.02 1.07 58MV(B,C)120---20 CNPV*6124A** 1.01 1.04 58MV(B,C)120---20
CSPH*6012A** 1.00 1.04 58MV(B,C)120---20
CAP**6021A** 1.03 1.12 59*N*A100V21**20 CAP**6024A** 1.03 1.11 59*N*A100V21**20 CAP**6025A** 1.02 1.10 59*N*A100V21**20
CNPH*6024A** 1.00 1.08 59*N*A100V21**20 CNPH*6124A** 1.05 1.12 59*N*A100V21**20
CNPV*6024A** 0.99 1.07 59*N*A100V21**20 CNPV*6124A** 1.06 1.12 59*N*A100V21**20
CSPH*6012A** 0.98 1.05 59*N*A100V21**20
* Tested combination. { The kW values include the compressor, outdoor fa n motor, and indoor blower motor. The kW from supplement heaters shoul d be added to these values to obtai n total system kilowatts.
}The Btuh heating capacity values shown are net integrated values from which the defrost effect has been subtracted. The Btuh heating from supplement heaters should be added to those values to obtain total system capacity.
NOTE: When the required data falls between the published data, interpolation may be performed. Extrapolation is not an acceptable practice. EDB —EnteringDryBulb
25VNA

Carrier 25VNA Specifications

General

Refrigerant	R-410A
Energy Star Certified	Yes
Stages	Variable
HSPF2	Up to 9.5
Compressor Type	Variable Speed
Cooling Capacity	2-5 tons
Heating Capacity	2-5 tons
Warranty	10-year parts limited warranty
