Carrier 25VNA Product Data

15
TESTED AHRI COMBINATION RATINGS* NOTE: Ratings contained in this document are subject to change at any time. For AHRI ratings certificates, please refer to the AHRI directory www.ahridirectory.org Additional ratings and system combinations can be accessed via the Carrier database at: http://cactaxcredits.info/carrier-ratings/ac_ratings_sr
ch.php
Equipment performance calculator can be accessed at:
http://rpmob.wrightsoft.com/
Model Number Coil Model Number
Furnace Model
Number
Clg.
Cap.
High
Clg.
Cap.
Low
EER SEER
ID CFM High Temp
HSPF
Low Temp
High Lo w E Capacity ECOP H Capacity HCOP
25VNA024A**30 FE4ANB006+UI 25,200 19,200 16.0 20.5 900 650 23,600 4.70 13.0 24,800 2.54 25VNA036A**30 FE4ANB006+UI 35,000 23,200 14.5 20.5 1200 875 33,400 4.40 13.0 31,600 2.54 25VNA048A**30 FE4ANB006+UI 47,500 34,800 13.5 18.3 1500 1100 45,500 4.12 12.5 47,500 2.22 25VNA060A**30 FE4ANB006+UI 56,000 38,000 12.7 18.0 1500 1100 55,500 3.86 12.0 52,500 2.22
* Ratings are net values r ef l ecting the effects of circulating f an heat. Supplemental electric heat is not included. Ratings are based on: Cooling Standard: 80_F(27_C) db 67_F(19_C) wb indoor entering air temperature and 95_F(35_C) db air entering outdoor unit.
High---Temp Heating Standard: 70_F(21_C) db indoor entering air temperature and 47_F(8_C) db 43° F (6_C) wb air entering outdoor unit.
Low--- Temp Heating Standard: 70_F(21_C) db indoor entering air temperature and 17_F ( --- 8 _C) db 15° F ( ---9_C) wb air entering outdoor unit.
COP — Coefficient of Performance EER — Energy Efficiency Ratio HSPF — Heating Seasonal Performance Factor SEER — Seasonal Energy Efficiency Ratio UI —UserInterface
25VNA

Carrier 25VNA Specifications

General

Refrigerant	R-410A
Energy Star Certified	Yes
Stages	Variable
HSPF2	Up to 9.5
Compressor Type	Variable Speed
Cooling Capacity	2-5 tons
Heating Capacity	2-5 tons
Warranty	10-year parts limited warranty
