Carrier 38CKX - Condenser Only Ratings (S.I.)

10
Condenser only ratings (S.I.)
See notes on pg. 11
SST
°C
CONDENSER ENTERING AIR TEMPERATURES °C
20 24 28 32 36 40 44 48 52
38CKX024-71
–2
TCG 6.03 5.69 5.34 5.00 4.66 4.33 4.00 3.67 3.36
KW 1.77 1.85 1.92 1.98 2.03 2.07 2.10 2.12 2.13
SDT 35.1 38.9 42.7 46.5 50.3 54.0 57.7 61.4 65.1
0
TCG 6.52 6.16 5.80 5.44 5.09 4.74 4.39 4.05 3.71
KW 1.82 1.91 1.98 2.05 2.11 2.16 2.20 2.23 2.25
SDT 35.9 39.7 43.5 47.3 51.1 54.8 58.5 62.2 65.9
2
TCG 7.02 6.64 6.26 5.89 5.51 5.15 4.78 4.43 4.07
KW 1.88 1.97 2.05 2.13 2.19 2.25 2.30 2.33 2.36
SDT 36.7 40.5 44.3 48.1 51.9 55.6 59.3 62.9 66.6
4
TCG 7.53 7.14 6.74 6.35 5.96 5.58 5.20 4.82 4.45
KW 1.93 2.03 2.12 2.20 2.27 2.34 2.39 2.44 2.47
SDT 37.5 41.4 45.2 48.9 52.7 56.4 60.1 63.7 67.4
6
TCG 8.07 7.65 7.24 6.83 6.42 6.02 5.62 5.23 4.84
KW 1.98 2.09 2.19 2.27 2.36 2.43 2.49 2.54 2.59
SDT 38.4 42.3 46.1 49.8 53.5 57.2 60.9 64.6 68.2
8
TCG 8.62 8.18 7.75 7.32 6.90 6.47 6.06 5.65 5.24
KW 2.04 2.15 2.25 2.35 2.44 2.52 2.59 2.65 2.70
SDT 39.3 43.2 47.0 50.7 54.4 58.1 61.8 65.4 69.0
10
TCG 9.19 8.74 8.29 7.84 7.39 6.95 6.52 6.08 5.65
KW 2.10 2.21 2.32 2.43 2.52 2.61 2.69 2.76 2.82
SDT 40.3 44.1 47.9 51.7 55.4 59.1 62.7 66.3 69.9
38CKX036-71, 91
–2
TCG 8.75 8.26 7.78 7.30 6.83 6.36 5.88 5.41 4.95
KW 2.48 2.60 2.70 2.80 2.88 2.95 3.00 3.04 3.07
SDT 30.9 35.1 39.1 43.1 47.1 51.0 55.0 58.9 62.9
0
TCG 9.48 8.97 8.47 7.97 7.47 6.98 6.49 6.00 5.51
KW 2.55 2.68 2.79 2.89 2.99 3.07 3.13 3.19 3.23
SDT 31.4 35.6 39.6 43.6 47.6 51.5 55.4 59.3 63.2
2
TCG 10.2 9.68 9.16 8.63 8.11 7.60 7.09 6.58 6.07
KW 2.62 2.76 2.88 2.99 3.10 3.19 3.27 3.33 3.38
SDT 31.9 36.1 40.1 44.1 48.1 52.0 55.8 59.7 63.5
4
TCG 11.0 10.4 9.88 9.33 8.78 8.24 7.71 7.18 6.66
KW 2.69 2.83 2.97 3.09 3.21 3.31 3.40 3.47 3.54
SDT 32.4 36.6 40.7 44.7 48.7 52.6 56.4 60.2 64.0
6
TCG 11.8 11.2 10.6 10.0 9.48 8.91 8.36 7.80 7.25
KW 2.76 2.91 3.06 3.19 3.32 3.43 3.53 3.62 3.69
SDT 32.9 37.1 41.2 45.3 49.3 53.2 57.0 60.8 64.6
8
TCG 12.6 12.0 11.4 10.8 10.2 9.60 9.02 8.44 7.87
KW 2.83 2.99 3.15 3.29 3.43 3.55 3.66 3.76 3.85
SDT 33.5 37.7 41.8 45.9 49.9 53.8 57.6 61.4 65.2
10
TCG 13.4 12.8 12.2 11.6 11.0 10.3 9.72 9.11 8.51
KW 2.90 3.07 3.24 3.39 3.54 3.68 3.80 3.90 4.00
SDT 34.0 38.3 42.5 46.5 50.5 54.5 58.3 62.1 65.8
38CKX048-91
–2
TCG 11.7 11.3 10.9 10.5 10.0 9.58 9.15 8.76 8.42
KW 3.18 3.41 3.64 3.89 4.15 4.42 4.71 5.02 5.34
SDT 33.9 38.1 42.2 46.4 50.4 54.5 58.6 62.5 66.3
0
TCG 12.7 12.2 11.8 11.4 10.9 10.4 9.99 9.56 9.17
KW 3.25 3.48 3.73 3.98 4.24 4.52 4.83 5.14 5.47
SDT 34.7 38.9 43.0 47.2 51.2 55.3 59.4 63.3 67.2
2
TCG 13.6 13.2 12.8 12.3 11.8 11.3 10.8 10.4 9.93
KW 3.32 3.56 3.81 4.07 4.34 4.63 4.94 5.26 5.60
SDT 35.5 39.7 43.8 48.0 52.0 56.1 60.2 64.2 68.0
4
TCG 14.6 14.2 13.7 13.2 12.7 12.2 11.7 11.2 10.7
KW 3.40 3.64 3.90 4.16 4.44 4.74 5.05 5.38 5.73
SDT 36.3 40.5 44.6 48.8 52.9 56.9 61.0 65.0 68.9
6
TCG 15.6 15.1 14.6 14.1 13.6 13.0 12.5 12.0 11.4
KW 3.47 3.71 3.98 4.25 4.54 4.84 5.17 5.51 5.86
SDT 37.1 41.3 45.4 49.6 53.7 57.7 61.8 65.8 69.7
8
TCG 16.6 16.1 15.6 15.0 14.5 13.9 13.3 12.8 12.2
KW 3.54 3.79 4.06 4.35 4.64 4.95 5.28 5.63 5.99
SDT 37.8 42.1 46.2 50.4 54.5 58.5 62.6 66.6 70.6
10
TCG 17.6 17.1 16.5 16.0 15.4 14.8 14.2 13.6 12.9
KW 3.61 3.87 4.15 4.44 4.74 5.06 5.39 5.75 6.12
SDT 38.6 42.9 47.0 51.2 55.3 59.3 63.4 67.4 71.4
