REMOVAL PROCEDURE OF OUTDOOR UNIT -- 42K
Steps Procedure
1. Disassemble the cover plate
2. Disassemble the front panel
3. Disassemble the panel on the right side
① Remove the fixed screws on the cover plate by
using a screwdriver.
② Remove the cover plate.
① Remove the fixed screws on the front panel by
using a screwdriver.
② Remove the front panel.
① Remove the fixed screws on the panel by using
a screwdriver.
② Remove the panel on the right side.
