11
AIR FLOW DATA
SYSTEM SIZE 9 12
Indoor (CFM)
High 280 280
Medium 250 250
Low 220 220
Outdoor (CFM) 945 945
SOUND PRESSURE
SYSTEM SIZE 9 12
Cooling operation Indoor Sound
Pressure
dBa (L/M/H) 37/38/41 34/41/45
Heating operation Indoor Sound
Pressure
dBa (L/M/H) 37/38/41 34/41/45
Outdoor sound pressure level dBa 55.5 56
SOUND POWER
SYSTEM SIZE 9 12
Cooling operation Indoor Sound
Power
dBa (L/M/H) 46/47/50 44/51/55
Heating operation Indoor Sound
Power
dBa (L/M/H) 46/47/50 44/51/55
Outdoor sound power level dBa 65 66
ELECTRICAL DATA
UNIT
SIZE
OPER. VOLTAGE
MAX / MIN*
COMPRESSOR OUTDOOR FAN INDOOR FAN
MCA
MAX FUSE CB
AMP
V --- P H --- H Z RLA V --- P H --- H Z FLA HP W V --- P H --- H Z FLA HP W
9
253 / 187 208---230/1/60
5.3
208---230/1/60
3 0.053 40
208---230/1/60
0.21 0.027 20
15 15
12 5.7
3 0.053 40 0.21 0.027 20
15 15
*Permissible limits of the voltage range at which the unit will operate satisfactorily
LEGEND
FLA -- Full Load Amps
LRA -- Locked Rotor Amps
MCA -- Minimum Circuit Amps
RLA -- Rated Load Amps
