7
SPECIFICATIONS
SYSTEM
SIZE 9 12
Outdoor Model 3 8 M A Q B 0 9 --- --- --- 3 3 8 M A Q B 1 2 --- --- --- 3
Indoor Model 40MBQB09F--- ---3 40MBQB12F--- ---3
Energy Star YES YES
Performance
Cooling Rated Capacity Btu/h 9,000 12,000
Coolin g C ap. Rang e Min --- Max Btu/h 3,500~ 11,000 4,000~ 13,000
SEER 20.0 20.5
EER 12.5 12.5
Heating Rated Capacity Btu/h 10,000 12,000
Heating Cap. Range Min --- Max Btu/h 4,500~ 11,500 5,000~ 13,500
HSPF 10 10
COP W/W 3.35 3.58
Controls
Wireless Remote Controller (° F/° C Convertible) Standard Standard
Wired Remote Controller (° F/° C Convertible) Optional Optional
Operating
Range
Cooling Outdoor DB Min --- Max °F ---4~ 122 ---4~ 122
Heating Outdoor DB Min --- Max °F --- 4~ 86 --- 4~ 86
Piping
Total Piping Length Ft. 82 82
Piping Lift
*
Ft. 32 32
Pipe Connection Size --- Liquid In. 1/4 1/4
Pipe Connection Size --- Suction In. 3/8 1/2
Refrigerant
Typ e R410A R410A
Design Pressure PSIG 550 550
Metering Device EEV EEV
Charge Lb. 2.76 2.76
Outdoor Coil
Face Area Sq. Ft. 9.2 9.2
No. Rows 2 2
Fins per inch 21 21
Circuits 4 4
Indoor Coil
Face Area (sq. ft.) Sq. Ft. 2.1 2.1
No. Rows 2 2
Fins per inch 19 19
Circuits 2 2
Compressor
Typ e Hermetic Rotary DC Inverter Compressor
Model ASM98D1UFZA ASM108D1UFZA
Oil Type VG74 VG74
Oil Charge Fl. Oz. 12.5 12.5
Rated Current RLA 5.3 5.7
Electrical
Voltage, Phase, Cycle V/Ph/Hz 208/230--- 1--- 60 208/230--- 1--- 60
Power Supply Indoor unit powered from outdoor unit
MCA A. 15 15
M O C P --- F u s e R a t i n g A. 15 15
Outdoor
Unit Width In. 31.9 31.9
Unit Height In. 22.0 22.0
Unit Depth In. 12.2 12.2
Net Weight Lbs. 82.5 82.5
Airflow CFM 945 945
Sound Pressure dB(A) 56 56
Indoor
Unit Width In. 27.6 27.6
Unit Height In. 8.3 8.3
Unit Depth In. 23.6 23.6
Net Weight Lbs. 32.4 32.4
Number of Fan Speeds 3 3
Airflow (lowest to highest) CFM 220/250/280 220/250/280
Sound Pressure (lowest to highest) dB(A) 37/38/41 34/41/45
*Condensing unit above or below the indoor unit
