DISASSEMBLY INSTRUCTIONS SIZES 36 AND 48 (CONT)
6The
expansion
valve
How to remove the expansion
valve
1) Complete the steps in the
Fan Assembly and Panel
Plate sections.
2) Remove the electrical parts
as described in the
Electrical Parts section.
3) Remove the coil.
4) Detach the welded parts of
the expansion valves and
the pipes.
Expansion
valves
