DIAGNOSIS AND SOLUTION (CONT)
Over voltage or too low voltage protection diagnosis and solution (P1) (Cont)
A210520
Fig. 50 —Test
NOTE: Measure the DC voltage between the P and N port. The normal value should be around 310V.
