SG-38MPRA-02 Specifications subject to change without notice. 3
SPECIFICATIONS
Table 2 — Specifications
* Condensing unit above or below the indoor unit.
HEAT PUMP
SYSTEM
SIZE 9 12 18 24
OUTDOOR MODEL 38MPRAQ09AA3 38MPRAQ12AA3 38MPRAQ18AA3 38MPRAQ24AA3
ELECTRICAL
Voltage, Phase, Cycle V/Ph/Hz 208/230-1-60 208/230-1-60 208/230-1-60 208/230-1-60
MCA A. 13 15 18 20
MOCP - Fuse Rating A. 15 20 30 30
OPERATING
RANGE
Cooling Outdoor DB Min - Max °F (°C) -22~122 (-30~50) -22~122 (-30~50) -22~122 (-30~50) -22~122 (-30~50)
Heating Outdoor DB Min - Max °F (°C) -22~86 (-30~30) -22~86 (-30~30) -22~86 (-30~30) -22~86 (-30~30)
PIPING
Total Piping Length ft (m) 98 (30) 98 (30) 98 (30) 98 (30)
Piping Lift
*
ft (m) 49 (15) 49 (15) 65 (20) 65 (20)
Pipe Connection Size - Liquid in (mm) 1/4 (6.35) 1/4 (6.35) 3/8 (9.52) 3/8 (9.52)
Pipe Connection Size - Suction in (mm) 3/8 (9.52) 1/2 (12.7) 5/8 (15.9) 5/8 (15.9)
REFRIGERANT
Type R410A R410A R410A R410A
Charge lbs (kg) 3.5 (1.58) 3.5 (1.58) 5.7 (2.6) 6.5 (2.95)
Metering Device EEV EEV EEV EEV
OUTDOOR
COIL
Face Area Sq. Ft. 5.1 5.1 8.2 8.2
No. Rows 2 2 2 3
Fins per inch 21 21 22 22
Circuits 6 6 4 4
COMPRESSOR
Type Rotary Inverter Rotary Inverter Rotary Inverter Rotary Inverter
Model ATM115D43UFZ2 ATM115D43UFZ2 KTM240D57UMT KTM240D57UMT
Oil Type VG74 VG74 VG74 VG74
Oil Charge Fl. Oz. 16.9 16.9 22.7 22.7
Rated Current RLA 8.0 8.0 13.1 13.5
OUTDOOR
Unit Width in (mm) 33.27 (845) 33.27 (845) 37.24 (946) 37.24 (946)
Unit Height in (mm) 27.64 (702) 27.64 (702) 31.89 (810) 31.89 (810)
Unit Depth in (mm) 14.29 (363) 14.29 (363) 16.14 (410) 16.14 (410)
Net Weight lbs (kg) 107.59 (48.8) 108.47 (49.2) 135.4 (61.4) 145.1 (65.8)
Airflow CFM 1,380 1,380 2,236 2,236
Sound Pressure dB(A) 55.5 56.0 61.5 62.0
