Physical data
* Tube sizes are for lengths up to 50 ft (15.24m). For lengths over 50 ft (15.24m), consult Residential Split System Long-Line Application Guideline.
NOTE:
See unit Installation Instructions for proper installation.
METERING DEVICE
*Piston listed is for any approved coil combination.
UNIT SIZE-SERIES 024-70 036-70, 90 048-70, 90, 92 060-90, 92
OPERATING WT (Lb/Kg)
140 / 63.6 216 / 97.8 216, 216, 224 / 97.8, 97.8, 101.8 257, 259 / 116.4, 117.5
COMPRESSOR
Manufacturer
Type
Copeland
Recip
Copeland
Recip
Millennium, Millennium, Copeland
Scroll
Millennium, Copeland
Scroll
REFRIGERANT
Control
Charge (Lb/Kg) @ 15 ft (4.57m)
R-22
Piston
4.84 / 2.20 7.93 / 3.60 5.32, 5.32, 7.25 / 2.41, 2.41, 3.29 10.95, 10.75 / 4.97, 4.88
CONDENSER FAN
Propeller Type, Direct Drive
Air Discharge
Vertical
Air Qty (CFM / L/S)
2160 / 1019 2750 / 1298 2750 / 1298 2750 / 1298
Motor HP
1/10 1/4 1/4 1/4
Motor RPM (50 Hz)
850 900 900 900
CONDENSER COIL
Face Area (Sq ft/m
2
)
12.4 / 1.15 22.4 / 2.08 18.7 / 1.74 18.7 / 1.74
Fins per In. / Fins per Cm
20 / 8 20 / 8 20 / 8 20 / 8
Rows
1112
Circuits
2346
CONNECTION (In./mm ID)
Vapor
Liquid
Sweat
5/8 / 15.875 3/4 / 19.05 7/8 / 22.225 7/8 / 22.225
3/8 / 9.525
REFRIG TUBES* (In./mm OD)
Vapor (0–50 Ft (15.24m)
Tube Length)
5/8 / 15.875 3/4 / 19.05 7/8 / 22.225 1-1/8 / 28.575
Vapor (Max Diameter for
Long-Line Applications)
3/4 / 19.05 7/8 / 22.225 1-1/18 / 28.575
Liquid (0–50 Ft (15.24m) Tube
Tube Length)
3/8 / 9.525
Liquid (For Long-Line
Applications)
3/8 / 9.525
UNIT
SIZE-SERIES
OUTDOOR
PISTON
INDOOR
PISTON*
024-70
49 63
036-70, 90
61 73
048-70, 90
73 88
048-92
73 90
060-90
76 98
060-92
76 96
