Electrical data
* Permissible limits of the voltage range at which unit will operate satisfactorily. Operation outside these limits may result in unit failure.
† Time-delay fuse.
‡ Length shown is as measured 1 way along the wire path between the unit and the service panel for voltage drop not to exceed 2%.
** If wire is applied at ambient greater than 30°C (86°F), consult Table 310-16 of the NEC (ANSI/NFPA 70). The ampacity of nonmetallic-sheathed-
cable (NM), trade name ROMEX, shall be that of 60°C (140°F) conductors, per the NEC (ANSI/NFPA 70) Article 336-30.
If other than uncoated (non-plated), 60° or 75°C (140° or 167°F) insulation, copper wire (solid wire for 10 AWG and smaller, stranded wire for
larger than 10 AWG) is used, consult applicable tables of the NEC (ANSI/NFPA 70).
FLA — Full Load Amps
HACR — Heating, Air Conditioning, Refrigeration
LRA — Locked Rotor Amps
MCA — Minimum Circuit Amps
RLA — Rated Load Amps
NOTE: Control circuit is 24v on all units and requires external power source. Copper wire must be used from disconnect to unit. All motors/compres-
sors contain internal overload protection.
OUTDOOR
UNIT V/PH
OPER VOLTS* COMPRESSOR
FAN
FLA MCA
MIN WIRE
SIZE**
60°C/75°C
MAX
LENGTH
(Ft)‡
60°C/75°C
MAX
LENGTH
(m)‡
60°C/75°C
MAX FUSE†
OR HACR
TYPE CKT
BKR AMPSMax Min LRA RLA
024-70
230-1 253 207
68.0 11.5 1.4 15.8 14/14 55/39 16.7/11.9 25
036-70 94.0 16.5 1.6 22.2 12/12 65/47 19.8/14.3 35
048-70 140.0 19.2 1.6 25.6 10/10 96/70 29.3/21.3 40
036-90
400-3 440 360
42.0 6.4 0.7 8.7 14/14 260/247 79.2/75.3 15
048-90 66.5 8.0 0.7 10.7 14/14 165/157 50.3/47.9 15
048-92 63.0 7.9 0.7 10.7 14/14 165/157 50.3/47.9 15
060-90 73.0 9.5 0.7 12.6 14/14 165/157 50.3/47.9 20
060-92 74.0 9.0 0.7 11.9 14/14 165/157 50.3/47.9 20
