Carrier 38YCC - Dimensional Data (English Units); Unit Dimensions and Clearances (Inches)

9
Dimensions (English)
A97045
AIR DISCHARGE
AIR IN
A SQ
B
P
C
3
/8 -IN. DIA
TIEDOWN
KNOCKOUTS
(2) PLACES
2
7
/8″
1
1
/4″
H
G
F
E
FIELD CONTROL SUPPLY  CONN
7
/
8
-IN. DIA 
HOLE
FIELD POWER SUPPLY CONN 7
/
8
-IN. DIA HOLE WITH 
1
1
/
8
-IN. DIA KNOCKOUT 
AND 1
3
/
8
-IN. DIA 
KNOCKOUT
3
/
8
-IN. DIA LIQUID 
LINE CONN
D DIA VAPOR LINE CONN
L
K
J
AIR IN
M
N
AIR DISCHARGE
AIR IN
AIR IN
AIR DISCHARGE
NOTES:
1. Allow 30 in. clearance to service side of unit, 48 in. above unit, 6 in. on one side, 12 in.

on remaining side, and 24 in. between units for proper airflow. 2. Minimum outdoor operating ambient in cooling mode is 55°F (unless low ambient control is used) max. 125°F. 3. Maximum outdoor operating ambient in heating mode is 66°F. 4. Series designation is the 13th position of the unit model number. 5. Center of gravity .
DIMENSIONS (IN.)
UNIT
SIZE SERIES ABCDEFGHJKLMNP
MINIMUM MOUNTING
PAD DIMENSIONS
024 70 22-1/2 33-15/16 3-3/16 5/8 3-11/16 18-1/8 19-3/4 21-5/8 14-3/8 18-7/8 22-1/16 12-1/2 12 14 22-1/2 x 22-1/2 036 70, 90 30 39-15/16 3-1/4 3/4 6-1/2 23-1/2 27-1/4 29-1/8 20 26-3/8 29-9/16 15 15-3/4 15-1/2 30 x 30 048 70, 90 30 33-15/16 3-1/4 7/8 6-1/2 23-1/2 27-1/4 29-1/8 20 26-3/8 29-9/16 15 15-3/4 15-1/2 30 x 30 048 92 30 33-15/16 3-1/4 7/8 6-1/2 23-1/2 27-1/4 29-1/8 20 26-3/8 29-9/16 15-1/4 15-5/8 15-1/2 30 x 30 060 90 30 33-15/16 3-1/4 7/8 6-1/2 23-1/2 27-1/4 29-1/8 20 26-3/8 29-9/16 15-3/4 15-5/8 15 30 x 30 060 92 30 33-15/16 3-1/4 7/8 6-1/2 23-1/2 27-1/4 29-1/8 20 26-3/8 29-9/16 15-5/8 15-3/4 15-1/8 30 x 30
