Combination ratings
OUTDOOR
UNIT
AND
SOUND
RATING
(Bels)
INDOOR
UNIT
ARI STANDARD RATINGS*
Cooling Heating
TC
Seasonal Efficiency
Seasonal
Efficiency
HSPF
Factory-
Supplied
Enhance-
ment
Standard
Rating
Field-Supplied
Accessory**
High-Temp Low-Temp
TDR TXV TC COP TC COP
018-30
7.8/7.6
FB(4,5)AN(A,F)018† 16,500 TDR 10.20 — 10.20 18,000 2.94 11,100 2.00 6.80
F(A,B)4ANF018 16,500 TDR 10.20 — 10.20 18,000 2.94 11,100 2.00 6.80
FB(4,5)AN(A,F)024 17,000 TDR 10.50 — 10.50 18,200 3.10 11,300 2.06 7.00
F(A,B)4ANF024 17,000 TDR 10.50 — 10.50 18,200 3.10 11,300 2.06 7.00
FF1ANA018 16,500 TDR 10.50 — 10.50 18,000 2.98 11,000 2.02 6.80
FF1ANA024 17,000 TDR 10.50 — 10.50 18,400 3.12 11,200 2.06 7.00
FD3ANA024 17,000 NONE — 10.50 10.50 18,000 3.04 11,100 2.04 7.00
FC4BNF018 16,500 TDR & TXV 10.20 — — 18,000 2.94 11,100 2.00 6.80
FC4BNF024 17,000 TDR & TXV 10.50 — — 18,200 3.10 11,300 2.06 7.00
FG3AAA024 17,000 NONE — 10.50 10.50 18,000 3.00 11,200 2.02 6.90
CC5A/CD5AA018 16,700 NONE — 10.00 10.00 18,000 2.88 11,100 1.98 6.75
CC5A/CD5AA024 17,000 NONE — 10.50 10.50 18,000 3.04 11,200 2.02 7.00
CD3(A,B)A018 16,700 NONE — 10.00 10.00 18,000 2.88 11,100 1.98 6.75
CD3(A,B)A024 17,000 NONE — 10.50 10.50 18,000 3.04 11,200 2.02 7.00
CF5AA024 17,000 NONE — 10.50 10.50 18,000 3.08 11,200 2.04 7.00
CE3AA024 17,000 NONE — 10.50 10.50 18,000 3.06 11,200 2.04 7.00
018-31
7.6/7.6
F(A,B)4ANF018† 17,000 TDR 10.20 — 10.20 18,000 2.96 10,600 2.10 6.80
FB(5,4)AN(A,F)018 17,000 TDR 10.20 — 10.20 18,000 2.96 10,500 2.10 6.80
FB(5,4)AN(A,F)024 17,500 TDR 10.50 — 10.50 18,200 3.12 10,900 2.18 7.00
F(A,B)4ANF024 17,500 TDR 10.50 — 10.50 18,200 3.12 10,900 2.18 7.00
FC4BNF024 17,500 TDR & TXV 10.50 — — 18,200 3.12 10,900 2.18 7.00
FD3ANA018 17,000 NONE — 10.00 10.00 18,000 2.94 10,800 2.10 6.80
FD3ANA024 17,500 NONE — 10.50 10.50 18,000 3.12 10,700 2.20 7.00
FF1ANA018 17,000 TDR 10.50 — 10.50 17,900 3.06 10,400 2.18 6.80
FF1ANA024 17,500 TDR 10.50 — 10.50 18,400 3.14 10,900 2.20 7.00
FG3AAA024 17,500 NONE — 10.50 10.50 18,000 3.06 10,800 2.16 6.90
CC5A/CD5A/CD5BA018 17,000 NONE — 10.00 10.00 17,900 2.92 10,600 2.10 6.80
CD3(A,B)A018 17,000 NONE — 10.00 10.00 17,900 2.92 10,600 2.10 6.80
CC5A/CD5A/CD5BA024 17,500 NONE — 10.50 10.50 18,000 3.04 10,800 2.14 7.00
CD3(A,B)A024 17,500 NONE — 10.50 10.50 18,000 3.04 10,800 2.14 7.00
CE3AA024 17,500 NONE — 10.50 10.50 18,000 3.06 10,800 2.16 7.00
CF5AA024 17,500 NONE — 10.50 10.50 18,000 3.08 10,800 2.16 7.00
024-30,-31
7.8/7.6
FB(4,5)AN(A,F)024† 22,400 TDR 10.50 — 10.50 20,800 3.06 13,900 2.18 7.00
F(A,B)4ANF024 22,400 TDR 10.50 — 10.50 20,800 3.06 13,900 2.18 7.00
FB4AN(A,F)030 22,800 TDR 11.00 — 11.00 20,800 3.08 13,900 2.18 7.00
F(A,B)4ANF030 22,800 TDR 11.00 — 11.00 20,800 3.08 13,900 2.18 7.00
FB5BNA030 22,800 TDR 11.00 — 11.00 20,800 3.08 13,900 2.18 7.00
FB5AN(A,F)030 22,400 TDR 11.00 — 11.00 20,800 3.00 13,800 2.16 6.95
FK4ANF002 23,000 TDR & TXV 12.00 — — 20,000 3.20 13,500 2.28 7.30
FF1ANA024 22,400 TDR 10.50 — 10.50 21,000 3.06 13,900 2.18 7.00
FF1ANA030 22,800 TDR 10.50 — 10.50 21,200 3.08 14,100 2.16 7.00
FD3ANA024 22,000 NONE — 10.50 10.50 20,600 2.98 13,700 2.16 6.80
FD3ANA030 22,600 NONE — 10.50 10.50 21,000 3.04 14,100 2.16 7.00
FC4BNF024 22,400 TDR & TXV 10.50 — — 20,800 3.06 13,900 2.18 7.00
FC4BNF030 22,800 TDR & TXV 11.00 — — 20,800 3.08 13,900 2.18 7.00
FG3AAA024 22,000 NONE — 10.50 10.50 20,800 2.96 13,800 2.14 6.85
CC5A/CD5AA024 22,400 NONE — 10.50 10.50 20,800 2.98 13,800 2.14 6.80
CC5A/CD5AA030 22,800 NONE — 10.60 10.60 20,200 2.98 13,800 2.16 6.80
CC5A/CD5AW030 22,800 NONE — 10.60 — 20,200 2.98 13,800 2.16 6.80
CD3(A,B)A024 22,400 NONE 10.20 11.00 11.00 20,800 2.98 13,800 2.14 6.80
CD3(A,B)A030 22,800 NONE 10.20 11.00 11.00 20,200 2.98 13,800 2.16 6.80
CF5AA024 22,600 NONE — 10.50 10.50 20,800 3.02 13,800 2.16 7.00
CE3AA024 22,600 NONE — 10.50 10.50 20,800 3.02 13,800 2.16 7.00
CE3AA030 22,800 NONE — 10.50 10.50 20,800 3.08 13,900 2.18 7.00
030-30,-31
7.6/7.4
FB4AN(A,F)030† 30,000 TDR 10.10 — 10.10 31,400 3.10 21,000 2.26 7.20
F(A,B)4ANF030 30,000 TDR 10.10 — 10.10 31,400 3.10 21,000 2.26 7.20
FB5BNA030 30,000 TDR 10.10 — 10.10 31,400 3.10 21,000 2.26 7.20
FB5AN(A,F)030 29,400 TDR 10.00 — 10.00 31,200 3.00 20,800 2.20 7.00
FB(4,5)AN(A,F)036 30,000 TDR 10.00 — 10.00 32,000 3.12 21,200 2.26 7.20
F(A,B)4ANF036 30,000 TDR 10.00 — 10.00 32,000 3.12 21,200 2.26 7.20
FK4ANF003 30,400 TDR & TXV 11.00 — — 31,400 3.38 20,600 2.40 7.50
FF1ANA030 30,000 TDR 10.00 — 10.00 31,800 3.10 21,200 2.24 7.20
FC4BNF030 30,000 TDR & TXV 10.10 — — 31,400 3.10 21,000 2.26 7.20
FC4BNF033 31,000 TDR & TXV 10.50 — — 31,800 3.24 21,000 2.32 7.40
FC4BNF036 30,000 TDR & TXV 10.00 — — 32,000 3.12 21,200 2.26 7.20
FG3AAA036 30,000 NONE — 10.00 10.00 31,600 3.12 21,000 2.26 7.20
CC5A/CD5AA030 30,000 NONE — 10.00 10.00 31,400 3.00 20,800 2.20 6.80
CC5A/CD5AW030 30,000 NONE — 10.00 10.00 31,400 3.00 20,800 2.20 6.80
CC5A/CD5AA036 30,400 NONE — 10.00 10.00 31,600 3.18 21,000 2.28 7.20
CD5AW036 30,400 NONE — 10.00 10.00 31,600 3.18 21,000 2.28 7.20
CD3(A,B)A030 30,000 NONE — 10.00 10.00 31,400 3.00 20,800 2.20 6.80
CD3(A,B)A036 30,400 NONE — 10.00 10.00 31,600 3.18 21,000 2.28 7.20
CF5AA036 30,400 NONE — 10.00 10.00 31,600 3.16 21,000 2.28 7.20
CE3AA030 30,000 NONE — 10.00 10.00 31,600 3.10 21,000 2.26 7.20
CE3AA036 30,200 NONE — 10.00 10.00 31,600 3.14 21,000 2.28 7.20
See notes on pg. 9.
