Carrier 38YKB User Manual

10
Detailed cooling capacities*
See notes on pg. 16.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES ° F
85 95 105 115
CFM EWB
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38YKB018-30 Outdoor Section With FB(4,5)AN(A,F)018 Indoor Section
500
72 18.1 8.91 1.65 17.5 8.72 1.82 16.8 8.48 1.99 15.9 8.17 2.19
67 16.8 11.4 1.64 16.0 11.1 1.79 15.2 10.8 1.97 14.4 10.5 2.15
63†† 15.5 11.1 1.62 14.8 10.8 1.77 14.1 10.4 1.94 13.3 10.1 2.13
62 15.2 13.7 1.61 14.5 13.3 1.77 13.8 13.0 1.94 13.1 12.6 2.12
57 14.6 14.6 1.60 14.1 14.1 1.76 13.5 13.5 1.93 12.9 12.9 2.12
575
72 18.4 9.28 1.69 17.8 9.11 1.85 17.1 8.87 2.03 16.2 8.57 2.22
67 17.1 12.1 1.67 16.3 11.8 1.83 15.5 11.5 2.00 14.6 11.1 2.19
63†† 15.8 11.7 1.65 15.1 11.4 1.80 14.3 11.1 1.97 13.5 10.7 2.16
62 15.6 14.6 1.65 14.8 14.2 1.80 14.1 13.8 1.97 13.4 13.4 2.16
57 15.2 15.2 1.64 14.6 14.6 1.80 14.0 14.0 1.97 13.4 13.4 2.15
650
72 18.6 9.60 1.72 18.0 9.47 1.88 17.3 9.24 2.06 16.3 8.94 2.25
67 17.4 12.8 1.70 16.5 12.5 1.86 15.7 12.1 2.03 14.8 11.8 2.22
63†† 16.1 12.3 1.68 15.3 12.0 1.83 14.5 11.7 2.00 13.7 11.3 2.19
62 15.9 15.4 1.68 15.2 15.0 1.83 14.5 14.5 2.00 13.8 13.8 2.19
57 15.7 15.7 1.67 15.1 15.1 1.83 14.5 14.5 2.00 13.8 13.8 2.19
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
FB(4,5)AN(A,F) 018 1.00 1.00 FG3AAA 024 1.03 1.02
024 1.03 1.03 CC5A/CD5AA 018 1.01 1.02
F(A,B)4ANF 018 1.00 1.00 024 1.03 1.02
FF1ANA 018 1.00 0.98 CD3(A,B)A 018 1.01 1.02
024 1.03 1.02 024 1.03 1.02
FD3ANA 024 1.03 1.01 CF5AA 024 1.03 1.02
FC4BNF 018 1.00 1.00 CE3AA 024 1.03 1.02
024 1.03 1.03 — — —
38YKB018-31 Outdoor Section With F(A,B)4ANF018 Indoor Section
600
72
19.1 9.51 1.80 18.2 9.22 1.92 17.2 8.88 2.03 16.1 8.51 2.14
67
17.8 12.4 1.76 16.8 12.0 1.87 15.7 11.6 1.97 14.5 11.1 2.06
63††
16.6 12.0 1.72 15.5 11.6 1.82 14.4 11.1 1.92 13.3 10.6 2.00
62
16.2 14.9 1.71 15.2 14.4 1.81 14.2 13.9 1.91 13.2 13.2 2.00
57 15.7 15.7 1.70 14.9 14.9 1.80 14.0 14.0 1.90 13.2 13.2 2.00
650
72
19.1 9.66 1.82 18.3 9.40 1.94 17.3 9.08 2.05 16.2 8.73 2.16
67
18.0 12.7 1.78 17.0 12.4 1.89 15.8 12.0 2.00 14.6 11.5 2.09
63††
16.7 12.4 1.75 15.7 12.0 1.85 14.5 11.5 1.94 13.4 11.0 2.03
62
16.4 15.5 1.74 15.4 14.9 1.84 14.4 14.3 1.93 13.5 13.5 2.03
57 16.1 16.1 1.73 15.2 15.2 1.83 14.3 14.3 1.93 13.5 13.5 2.03
700
72
19.2 9.79 1.83 18.4 9.58 1.96 17.4 9.28 2.07 16.3 8.94 2.18
67
18.1 13.1 1.81 17.1 12.8 1.92 16.0 12.4 2.02 14.7 11.9 2.11
63††
16.9 12.8 1.77 15.8 12.4 1.87 14.6 11.9 1.96 13.5 11.4 2.05
62
16.6 16.0 1.76 15.6 15.4 1.86 14.6 14.6 1.96 13.7 13.7 2.06
57 16.4 16.4 1.76 15.5 15.5 1.86 14.6 14.6 1.96 13.7 13.7 2.06
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
F(A,B)4ANF 018 1.00 1.00 FB(5,4)AN(A,F) 018 1.00 1.00
024 1.03 1.03 024 1.03 1.03
CC5A/CD5A/ 018 1.00 1.01 FC4BNF 024 1.03 1.02
CD5BA 024 1.03 1.02 FD3ANA 018 1.00 1.03
CD3(A,B)A 018 1.00 1.01 024 1.03 1.00
024 1.03 1.02
FF1ANA 018 1.00 0.97
CE3AA 024 1.03 1.02 024 1.03 1.02
CF5AA 024 1.03 1.02 FG3AAA 024 1.03 1.02
