9
COP
— Coefficient of Performance
HSPF
— Heating Seasonal Performance Factor
TC
— Total Capacity (Btuh)
* Ratings are net values reflecting the effects of circulating fan heat. Supplemental electric heat is not included. Ratings are based on:
Cooling Standard:
80˚F (27˚C) db 67˚F (19˚C) wb indoor entering air temperature and 95˚F (35˚C) db air entering outdoor unit.
High Temperature Heating Standard:
70˚F (21˚C) db indoor entering air temperature and 47˚F (8˚C) db 43˚F (6˚C) wb air entering outdoor unit.
Low Temperature Heating Standard:
70˚F (21˚C) db indoor entering air temperature and 17˚F (–8˚C) db 15˚F (–11˚C) wb air entering outdoor
unit.
† Outdoor section/indoor section combination tested in accordance with DOE test procedures for heat pumps. Ratings for other combinations are
determined under DOE computer simulation procedures.
‡ Rating without/with accessory sound blanket.
** Refer to TDR table prior to utilizing accessory TDR.
FIELD-SUPPLIED TDR TABLE
NOTE:
most cases, only 1 of the above should be used to achieve
TDR function. More than 1 of the methods listed above in a system
may cause degradation in performance.
060-30,-31
8.0/7.8
FC4BN(F,B)060 56,500 TDR & TXV 10.60 — — 61,000 3.26 39,500 2.40 7.60
FG3AAA060 56,000 NONE 10.60 11.00 11.00 59,500 3.20 38,500 2.40 7.50
CC5/CD5AA060 55,000 NONE 10.20 10.60 10.60 59,000 3.06 38,500 2.34 7.20
CC5/CD5AW060 56,000 NONE 10.60 11.00 11.00 59,500 3.24 38,500 2.42 7.50
CD3(A,B)A060 55,000 NONE 10.20 10.60 10.60 59,000 3.06 38,500 2.34 7.20
CE3AA060 57,000 NONE 10.60 11.00 11.00 60,000 3.26 38,500 2.42 7.50
METHOD PART/MODEL NO.
Time-Delay
Relay
KAATD0101TDR
Furnaces
with TDR
58SX, 58DX, 58SXA, 58SXB, 58DXA, 58DXC,
58SSC, 58DHC, 58WAV, 58ZAV, 58PAV, 58PAP,
58RAP, 58RAV, 58EJA
OUTDOOR
UNIT
AND
SOUND
RATING
(Bels)
INDOOR
UNIT
ARI STANDARD RATINGS*
Cooling Heating
TC
Seasonal Efficiency
Seasonal
Efficiency
HSPF
Factory-
Supplied
Enhance-
ment
Standard
Rating
Field-Supplied
Accessory**
High-Temp Low-Temp
TDR TXV TC COP TC COP
Combination ratings continued
