Detailed cooling capacities* continued
See notes on pg. 16.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES ° F
85 95 105 115
CFM EWB
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38YKB024-30, 31 Outdoor Section With FB(4,5)AN(A,F)024 Indoor Section
650
72
24.7 12.3 2.05 23.8 12.1 2.27 22.9 11.7 2.52 21.7 11.3 2.80
67
22.8 15.9 2.03 21.7 15.5 2.25 20.7 15.1 2.49 19.6 14.6 2.76
63††
21.0 15.4 2.01 20.1 15.0 2.22 19.1 14.5 2.46 18.1 14.1 2.73
62
20.7 19.1 2.01 19.8 18.7 2.22 18.8 18.2 2.45 17.9 17.7 2.73
57
20.1 20.1 2.00 19.4 19.4 2.21 18.6 18.6 2.45 17.8 17.8 2.72
750
72
25.1 12.9 2.09 24.2 12.7 2.32 23.2 12.4 2.57 22.1 12.0 2.85
67
23.2 17.0 2.07 22.1 16.6 2.29 21.0 16.1 2.53 20.0 15.7 2.81
63††
21.4 16.4 2.06 20.5 16.0 2.27 19.4 15.5 2.50 18.4 15.1 2.78
62
21.2 20.5 2.05 20.3 20.0 2.26 19.4 19.4 2.50 18.5 18.5 2.78
57
20.9 20.9 2.05 20.2 20.2 2.26 19.4 19.4 2.50 18.5 18.5 2.78
850
72
25.3 13.4 2.14 24.5 13.3 2.36 23.5 13.0 2.61 22.3 12.6 2.90
67
23.5 17.9 2.11 22.4 17.6 2.33 21.3 17.2 2.58 20.2 16.7 2.85
63††
21.8 17.4 2.10 20.7 17.0 2.31 19.7 16.5 2.55 18.7 16.1 2.82
62
21.7 21.7 2.10 20.8 20.8 2.31 20.0 20.0 2.55 19.1 19.1 2.83
57
21.7 21.7 2.10 20.8 20.8 2.31 20.0 20.0 2.55 19.1 19.1 2.83
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
FB(4,5)AN(A,F) 024 1.00 1.00 FC4BNF 024 1.00 1.00
FB4AN(A,F) 030 1.02 1.00 030 1.02 1.00
FB5AN(A,F) 030 1.00 1.00 FG3AAA 024 0.98 1.00
F(A,B)4ANF 024 1.00 1.00 CC5A/CD5AA 024 1.00 1.00
030 1.02 1.00 030 1.02 1.00
FB5BNA 030 1.02 1.00 CC5A/CD5AW 030 1.02 1.00
FK4ANF 002 1.03 0.95 CD3(A,B)A 024 1.00 1.00
FF1ANA 024 1.00 1.00 030 1.02 1.00
030 1.02 1.03 CF5AA 024 1.01 1.00
FD3ANA 024 0.98 0.99 CE3AA 024 1.01 1.00
030 1.01 1.03 030 1.02 1.00
