Carrier 38YKB User Manual

12
Detailed cooling capacities* continued
See notes on pg. 16.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES ° F
85 95 105 115
CFM EWB
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**
Capacity
MBtuh†
Total
System
Kw**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
38YKB030-30, 31 Outdoor Section With FB4AN(A,F)030 Indoor Section
950
72
33.2 16.6 2.98 32.0 16.1 3.29 30.6 15.7 3.62 29.0 15.1 3.98
67
31.1 21.5 2.94 29.7 21.0 3.24 28.1 20.4 3.56 26.5 19.7 3.91
63††
28.9 20.9 2.90 27.5 20.3 3.19 26.1 19.7 3.50 24.5 19.1 3.84
62
28.3 26.0 2.89 27.0 25.3 3.17 25.7 24.6 3.49 24.3 23.8 3.83
57
27.5 27.5 2.87 26.4 26.4 3.16 25.3 25.3 3.48 24.1 24.1 3.83
1050
72
33.5 17.0 3.03 32.3 16.6 3.33 30.9 16.2 3.67 29.3 15.7 4.03
67
31.4 22.4 2.98 30.0 21.9 3.28 28.4 21.3 3.60 26.7 20.7 3.95
63††
29.2 21.8 2.94 27.8 21.2 3.23 26.3 20.6 3.55 24.8 19.9 3.89
62
28.8 27.2 2.93 27.4 26.5 3.22 26.1 25.7 3.54 24.7 24.7 3.89
57
28.2 28.2 2.92 27.1 27.1 3.21 26.0 26.0 3.53 24.7 24.7 3.88
1150
72
33.8 17.5 3.07 32.6 17.1 3.38 31.1 16.7 3.71 29.5 16.2 4.07
67
31.6 23.2 3.02 30.2 22.7 3.32 28.7 22.3 3.65 27.0 21.6 4.00
63††
29.5 22.7 2.99 28.1 22.1 3.27 26.6 21.4 3.59 25.0 20.8 3.93
62
29.2 28.4 2.98 27.9 27.6 3.27 26.5 26.5 3.59 25.2 25.2 3.94
57
28.9 28.9 2.97 27.7 27.7 3.26 26.5 26.5 3.59 25.2 25.2 3.94
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
FB4AN(A,F) 030 1.00 1.00 FG3AAA 036 1.00 1.01
FB5AN(A,F) 030 0.98 1.00 CC5A/CD5AA 030 1.00 1.01
FB(4,5)AN(A,F) 036 1.00 1.03 036 1.01 1.01
F(A,B)4ANF 030 1.00 1.00 CC5A/CD5AW 030 1.00 1.01
036 1.00 1.03 CD5AW 036 1.01 1.01
FB5BNA 030 1.00 1.00 CD3(A,B)A 030 1.00 1.01
FK4ANF 003 1.01 0.96 036 1.01 1.01
FF1ANA 030 1.00 1.03 CF5AA 036 1.01 1.01
FC4BNF 030 1.00 1.00 CE3AA 030 1.00 1.00
033 1.03 1.01 036 1.01 1.01
036 1.00 1.03 — — —
