Carrier 40GXQ Service Manual

4
PRODUCT SPECIFICATIONS
System
System Model Number 53GXC009--- --- --- 1 5 3 G X C 0 1 2 --- --- --- 1 5 3 G X Q 0 0 9 --- --- --- 1 53GXQ012--- --- --- 1
System Voltage 115 V 115 V 115 V 115 V
Control Voltage 0 --- 2 4 v D C 0 --- 2 4 v D C 0 --- 2 4 v D C 0 --- 2 4 v D C
Capacity (Btuh) Clg/Htg 8,600/--- 12,000/--- 8,600/10,800 12,000/11,200
SEER/HSPF 16/--- 16/ --- 16/7.7 16/7.7
Refrigerant
Refrigerant Type R---410A
Design Pressure (PSIG) 560 560 560 560
Metering Device Capillary Tube at Outdoor
Charge (lb) 2.65 2.8 2.65 2.8
Compressor
Type Twin Rotary Inverter Driven
Model C---6RZ092H1AB C---6RZ092H1AB C---6RZ092H1AB C---6RZ092H1AB
O i l C h a r g e ( P O E --- o z ) 11.6 11.6 11.6 11.6
Rated Current (RLA) 4 3.92 4 3.92
Locked Rotor Amp (LRA) 33 33 33 33
Outdoor
Motor
Rpm/CFM 830/1060 830/1060 830/1060 830/1060
Diameter (in) .. No. of Blades 15.7 … 3 15.7 … 3 15.7 … 3 15.7 … 3
Motor (hp) 0.04 0.04 0.04 0.04
Capacitor 2.5µF/450VAC 2.5µF/450VAC 2.5µF/450VAC 2.5µF/450VAC
Outdoor
Coil
Face Area (sq. ft) 3.5
No. Rows 2
Fins per inch 18
Circuits 2
Indoor
Motor
Motor Watts/HP 20/0.027
Rpm/Cfm (High) 1200/290 1350/315 1200/290 1350/315
Rpm/Cfm (Medium) 1060/245 1200/268 1060/245 1200/268
Rpm/Cfm (Low) 700/224 1100/245 700/224 1100/245
Blower Diameter … Length (in) 3.8 … 23 3.6 … 24.3 3.8 … 23 3.6 … 24.3
Indoor
Coil
Face Area (sq. ft) 2.4 2.4 2.4 2.4
No. Rows 2
Fins per inch 18
Circuits 2 3 2 3
Refrigerant
Lines
Connection Type Flare
Liquid (Mix Phase) (in) OD 1/4”
Vapor Line (in) OD 1/2”
Condensate Drain (in) ID = 1/2” OD=5/8”
Maximum Length (ft) 65 65 65 100
Max Lift (Fan Coil Above) (ft) 35 35 35 50
Max Drop (Fan Coil Below) (ft) 35 35 35 50
