SPECIFICATIONS -- HEAT PUMP UNITS (MFQ SERIES)
System
Size (KBT U/Hr) 09 12 17 22
Outdoor Model 38MFQ009---1 38MFQ012---1 38MFQ012---3 38MFQ017---3 38MFQ022---3
Indoor Model 40MFQ009---1 40MFQ012---1 40MFQ012---3 40MFQ017---3 40MFQ022---3
AHRI Performance Ratin gs*
Cooling Rated Capacity Btu/h 9,000 12,000 17,000 22,000
Cooling Cap. Range Min - Max Btu/h 4,000-10,000 4,500-13,000 5,500-19,000 6,500-24,000
SEER 15
EER 10.5 10 9 9.5
Heating Rated Capacity Btu/h 9,000 12,000 18,000 22,000
Heating Cap. Range Min - Max Btu/h 4,000-10,500 4,500-13,000 5,500-19,500 6,500-24,500
HSPF 8.2
COP Btuh, W 8.1 8.0 9.7
Operating Range
Cooling Outdoor DB Min - Max °F 14 - 115
Heating Outdoor DB Min - Max °F 5-75
Cooling Indoor DB Min - Max °F 63 - 90
Heating Indoor DB Min - Max °F 32 - 86
Controls
Wireless (°C, °F, Convertible) Standard - Convertible
Wired (°C, °F, Convertible) Optional: KSACN0101CAC
Electrical
System Voltage-PH-Hz 115 -1 -60 208-230-1-60
Control Voltage 0-15V DC
Power Supply Indoor unit powered from outdoor unit
Outdoor - MCA 19 10 14 16
Outdoor - Fuse Rating (MOCP) 30 15 20 25
Outdoor Motor
Rpm/CFM 1000 / 945 940 / 945 860 / 1050 930 / 1390
Diameter (in) ... No. of Blades 15.8 … 3 16.7 … 3 18.3 … 3
Motor (hp) 0.31 0.33 0.68 0.72
Capacitor (µF) 6 2.5
Indoor Motor
Motor Watts/ HP 15 / 0.02 15 / 0.02 20 / 0.027 28 / 0.038 45 / 0.061
Rpm/CFM (High) 1200 / 192 1200 / 230 1200 / 232 1200 / 348 1200 / 547
Rpm/CFM (Medium) 1050 / 160 1050 / 194 1050 / 193 1050 / 294 1050 / 458
Rpm/CFM (Low) 900 / 131 900 / 158 900 / 157 900 / 236 900 / 368
Blower Diameter / Length (in) 3.7 / 21.3 3.9 / 28.7 4.2 / 30.7
Capacitor (µF) 3 1.5 3
Refrigerant
Refrigerant Type R410A
Design Pressure (PSIG) 550
Metering Device Capillary Tube in Outdoor Unit
Charge (lb) 2.6 2.87 3.52
Refrigerant Lines
Connection Type Flare
Pipe Connection Size - Liquid (In) OD 1/4 3/8
Pipe Connection Size - Suction (In) OD 3/8 1/2 5/8
Condensate Drain OD / ID (in) 0.65 / 0.63
Maximum Piping Length (ft) 65 98
Max Lift (Fan Coil Above) (ft) 25 30
Max Drop (Fan Coil Below) (ft) 25 30
Compressor
Type Rotary
Model DA108X1C-20FZ3 DA130M1C-31FZ DA150S1C-20FZ
Oil Charge (POE –oz (g)) 16.9 (480) 17.6 (500)
Capacitor 45µF / 250VAC 6µF / 450VAC None
Rated L oad Amps (RLA) 5.3 3.95 9.7
Locked Rotor Amp (LRA) 10 14 17
Outdoor Coil
Face Area (sq. ft.) 8.19 7.81 11
No. Ro ws 2
Fins per inch 17 18
Circuits 3 4
Indoor Coil
Face Area (sq. ft.) 2.53 2.98 1.61 5.29
No. Ro ws 1/2 2
Fins per inch 20 21
Circuits 2 4 5
Dimensions - O utdoor
Dimensions(WXHXD)In 35.8 x 23 x 13.2 34.9 x 25.4 x 14 38.0 x 29.7 x 15.6
NetWeight(lbs.) 70.5 82.7 103.6
Dimensions - Indoor
Dimensions(WXHXD)In 26.8 x 10.0 x 7.0 30.3 x 10.0 x 7.4 35.6 x 10.8 x 7.8 40.6 x 12.4 x 8.6
NetWeight(lbs.) 15.4 16.5 19.8 26.4
*Air Conditioning, H eating & Refrigeration Institute
--- Ratings are net values reflecting the effects of circulating fan heat. Ratings are
based on: Cooling Standard: 80_F (26.67_C) db, 67_F (19.44_C) wb air
entering indoor unit and 95_F(35_C) db air entering outdoor unit. High
Temperature Heating Standard: 70_F (21.11_C) db air entering indoor unit and
47_F (8.33_C) db, 43_F (6.11_C) wb air entering outdoor unit.
--- Ratings are based on 25 ft. (7.62 m) of interconnecting refrigerant lines.
--- All system ratings are based on fan coil units operating at high fan speed.
Consult Specification tables for airflows at all available fan speeds.
Legend
SEER --- Seasonal Energy Efficiency Ratio
EER --- Energy Efficiency Ratio
HSPF --- Heating Seasonal Performance Factor
COP --- Coefficient of Performance
MCA --- Minimum Circuit Amps
MOCP --- M a x . O v e r --- C u r r e n t P r o t e c t i o n
