Carrier 40MVC User Manual

12
PERFORMANCE DATA (CONT.)
COOLING CAPACITIES
38MVC(Q)012--3 / 40MVC(Q)012--3
Te m p _F(_C)
Air Entering
Condenser
(Edb)
A i r E n t e r i n g E v a p o r a t o r --- C f m / B F
339/0.04 367/0.04 427/0.05
A i r E n t e r i n g E v a p o r a t o r --- E w b _F(_C)
57
(13.89)
62
(16.67)
67
(19.44)
72
(22.22)
57
(13.89)
62
(16.67)
67
(19.44)
72
(22.22)
57
(13.89)
62
(16.67)
67
(19.44)
72
(22.22)
55
(12.78)
TCG 12.38 12.72 13.71 14.48 12.91 13.08 13.98 14.63 13.63 13.56 14.38 14.83
SHG 12.38 10.09 8.66 7.11 12.91 10.63 8.99 7.21 13.63 11.61 9.59 7.45
TC 12.35 12.69 13.69 14.45 12.88 13.05 13.95 14.61 13.60 13.53 14.35 14.81
kW 0.64 0.63 0.63 0.63 0.63 0.63 0.63 0.63 0.63 0.63 0.63 0.63
CMP 0.52 0.52 0.52 0.52 0.52 0.52 0.52 0.51 0.52 0.52 0.51 0.51
LDB 45.1 51.4 55.6 60.1 47.6 53.2 57.4 62.0 51.6 55.7 60.0 64.6
LWB 41.7 47.7 53.0 58.8 42.9 49.1 54.5 60.3 44.8 51.1 56.6 62.4
65
(18.33)
TCG 12.04 12.30 13.35 14.17 12.55 12.65 13.68 14.38 13.30 13.15 14.06 14.58
SHG 12.04 9.95 8.50 7.00 12.55 10.46 8.90 7.17 13.30 11.48 9.55 7.38
TC 12.01 12.28 13.33 14.14 12.52 12.62 13.65 14.36 13.27 13.12 14.03 14.56
kW 0.73 0.73 0.72 0.72 0.73 0.73 0.72 0.72 0.72 0.72 0.72 0.72
CMP 0.61 0.61 0.61 0.61 0.61 0.61 0.61 0.61 0.61 0.61 0.61 0.61
LDB 46.0 51.8 56.0 60.3 48.5 53.6 57.6 62.1 52.2 55.9 60.0 64.7
LWB 42.1 48.2 53.5 59.1 43.3 49.5 54.8 60.5 45.1 51.4 56.8 62.5
75
(23.89)
TCG 11.48 11.75 12.93 13.85 12.15 12.16 13.25 14.05 12.89 12.57 13.64 14.30
SHG 11.48 9.73 8.43 6.93 12.15 10.29 8.78 7.09 12.89 11.07 9.44 7.34
TC 11.46 11.72 12.90 13.83 12.12 12.13 13.22 14.03 12.86 12.55 13.62 14.27
kW 0.82 0.82 0.82 0.83 0.82 0.82 0.82 0.83 0.82 0.82 0.82 0.83
CMP 0.70 0.70 0.70 0.70 0.70 0.70 0.70 0.70 0.70 0.70 0.70 0.70
LDB 47.5 52.4 56.1 60.5 49.4 54.0 57.9 62.3 53.0 56.5 60.3 64.8
LWB 42.8 48.9 53.9 59.4 43.8 50.1 55.2 60.8 45.5 51.9 57.1 62.7
85
(29.44)
TCG 10.89 10.97 12.39 13.42 11.57 11.40 12.74 13.65 12.42 12.09 13.14 13.94
SHG 10.89 9.44 8.16 6.75 11.57 9.92 8.61 6.98 12.42 11.19 9.29 7.33
TC 10.86 10.94 12.36 13.39 11.54 11.36 12.71 13.62 12.39 12.06 13.12 13.91
kW 0.92 0.92 0.93 0.93 0.93 0.92 0.93 0.93 0.93 0.93 0.93 0.94
CMP 0.79 0.79 0.80 0.81 0.80 0.80 0.80 0.81 0.80 0.80 0.80 0.81
LDB 49.1 53.1 56.9 61.0 50.8 54.6 58.3 62.5 54.0 56.5 60.5 64.8
LWB 43.6 49.8 54.5 59.8 44.5 50.9 55.7 61.2 46.0 52.3 57.5 63.0
95
(35)
TCG 10.25 9.77 11.79 12.87 10.89 10.51 12.08 13.12 11.87 11.26 12.51 13.44
SHG 10.25 8.87 7.95 6.55 10.89 9.81 8.37 6.79 11.87 10.76 9.11 7.21
TC 10.22 9.74 11.76 12.84 10.86 10.48 12.05 13.09 11.84 11.23 12.48 13.41
kW 1.02 1.02 1.04 1.05 1.03 1.03 1.04 1.05 1.04 1.04 1.04 1.05
CMP 0.89 0.89 0.91 0.91 0.90 0.90 0.91 0.92 0.91 0.90 0.91 0.92
LDB 50.8 54.6 57.4 61.5 52.4 55.1 58.8 63.0 55.1 57.3 60.9 65.0
LWB 44.5 51.3 55.2 60.4 45.2 51.8 56.4 61.6 46.5 53.0 58.0 63.3
105
(40.56)
TCG 9.62 9.12 10.90 12.18 10.20 9.65 11.40 12.46 11.19 11.20 11.77 12.78
SHG 9.62 8.71 7.64 6.30 10.20 9.37 8.15 6.56 11.19 11.20 8.91 6.99
TC 9.59 9.09 10.87 12.15 10.17 9.62 11.37 12.43 11.16 11.17 11.75 12.76
kW 1.14 1.13 1.15 1.16 1.15 1.14 1.16 1.17 1.16 1.16 1.16 1.17
CMP 1.00 0.99 1.02 1.03 1.01 1.00 1.02 1.03 1.02 1.02 1.02 1.03
LDB 52.5 55.0 58.2 62.2 54.1 56.1 59.3 63.5 56.4 56.4 61.3 65.4
LWB 45.3 52.0 56.2 61.1 46.0 52.7 57.0 62.2 47.1 53.1 58.6 63.8
115
(46.11)
TCG 8.94 8.92 9.89 11.41 9.47 9.47 10.34 11.67 10.38 10.39 10.93 11.98
SHG 8.94 8.92 7.31 6.02 9.47 9.47 7.81 6.29 10.38 10.39 8.66 6.73
TC 8.91 8.90 9.86 11.38 9.44 9.44 10.31 11.65 10.35 10.37 10.90 11.95
kW 1.26 1.26 1.27 1.29 1.27 1.27 1.28 1.29 1.28 1.28 1.28 1.29
CMP 1.11 1.11 1.13 1.14 1.12 1.12 1.13 1.15 1.13 1.13 1.14 1.15
LDB 54.4 54.4 59.1 62.9 55.9 55.9 60.1 64.1 58.1 58.0 61.7 65.9
LWB 46.2 52.3 57.2 61.8 46.9 52.9 58.0 62.8 47.9 53.8 59.2 64.3
125
(51.67)
TCG 8.21 8.21 8.79 10.52 8.70 8.71 9.17 10.76 9.54 9.54 9.49 11.07
SHG 8.21 8.21 6.99 5.72 8.70 8.71 7.47 5.99 9.54 9.54 8.05 6.45
TC 8.18 8.18 8.76 10.50 8.68 8.68 9.15 10.73 9.51 9.51 9.46 11.04
kW 1.38 1.38 1.39 1.41 1.39 1.39 1.40 1.42 1.40 1.40 1.40 1.42
CMP 1.23 1.23 1.24 1.26 1.24 1.24 1.25 1.27 1.25 1.25 1.25 1.27
LDB 56.3 56.4 59.9 63.7 57.7 57.7 60.9 64.9 59.8 59.8 62.9 66.5
LWB 47.1 53.1 58.4 62.7 47.7 53.7 59.1 63.6 48.6 54.5 60.3 64.9
LEGEND
BF --- Bypass Factor
CMP --- Compressor
Edb --- Entering Dry Bulb
Ewb --- Entering Wet Bulb
k W --- To t a l Po w e r
LDB --- Leaving D ry Bulb
L W B --- L e a v i n g We t B u l b
SHG --- Gross Sensible Capacity (1000 Btu/hour)
TC --- Total Net Cooling Capacity (1000 Btu/hour)
TCG
---
Gross
Cooling
Capacity
(1000
Btu/hour)
NOTES:
1. Direct interpolation is permissible. Do not extrapolate.
2. The SHG is based on 80_F (26.67_C) edb temperature of air
entering indoor coil.
Below 80_F (26.67_C) edb, subtract (corr factor x cfm) from
SHG.
Above 80_F (26.67_C) edb, add (corr factor x cfm) to SHG.
Correction Factor = 1.10 x (1 --- BF) x (edb --- 80).
38/40MVC, MVQ
