13
PERFORMANCE DATA (CONT.)
COOLING CAPACITIES
38MVC(Q)018--3 / 40MVC(Q)018--3
Te m p _F(_C)
Air Entering
Condenser
(Edb)
Air Entering Evaporator --- Cfm/BF
502/0.04 568/0.04 631/0.05
Air Entering Evaporator --- Ewb (_F)
57
(13.89)
62
(16.67)
67
(19.44)
72
(22.22)
57
(13.89)
62
(16.67)
67
(19.44)
72
(22.22)
57
(13.89)
62
(16.67)
67
(19.44)
72
(22.22)
55
(12.78)
TCG 17.50 18.57 19.75 20.70 18.16 19.02 20.07 21.03 18.68 19.33 20.33 21.34
SHG 17.50 15.22 12.67 10.45 18.16 16.04 13.10 10.71 18.68 16.68 13.46 10.89
TC 17.33 18.40 19.58 20.53 17.98 18.85 19.90 20.85 18.50 19.15 20.15 21.17
kW 0.90 0.90 0.89 0.89 0.90 0.89 0.89 0.89 0.90 0.89 0.89 0.89
CMP 0.75 0.75 0.74 0.74 0.75 0.75 0.74 0.74 0.75 0.74 0.74 0.74
LDB 48.6 52.6 57.2 61.3 51.0 54.4 59.1 63.0 53.1 55.9 60.6 64.4
LWB 43.5 49.0 54.5 60.2 44.7 50.3 55.9 61.5 45.6 51.4 56.9 62.5
65
(18.33)
TCG 17.18 18.13 19.38 20.38 17.81 18.54 19.70 20.67 18.33 18.84 19.99 20.93
SHG 17.18 15.30 12.64 10.32 17.81 16.19 13.11 10.59 18.33 16.99 13.78 10.80
TC 17.01 17.95 19.21 20.21 17.63 18.37 19.53 20.50 18.16 18.66 19.82 20.75
kW 1.03 1.03 1.02 1.02 1.03 1.03 1.02 1.02 1.03 1.02 1.02 1.02
CMP 0.88 0.88 0.87 0.87 0.88 0.88 0.87 0.87 0.88 0.87 0.87 0.87
LDB 49.1 52.5 57.3 61.6 51.6 54.1 59.1 63.2 53.5 55.5 60.1 64.5
LWB 43.8 49.3 54.7 60.4 44.9 50.6 56.1 61.7 45.9 51.7 57.1 62.7
75
(23.89)
TCG 16.66 17.56 18.85 19.97 17.39 17.91 19.22 20.23 17.89 18.25 19.48 20.46
SHG 16.66 15.36 12.54 10.15 17.39 16.30 13.20 10.45 17.89 17.20 13.59 10.68
TC 16.48 17.39 18.68 19.79 17.21 17.74 19.04 20.06 17.71 18.08 19.31 20.28
kW 1.16 1.16 1.16 1.16 1.16 1.16 1.16 1.16 1.16 1.16 1.16 1.16
CMP 1.01 1.01 1.01 1.01 1.02 1.01 1.01 1.01 1.01 1.01 1.01 1.01
LDB 50.0 52.3 57.4 61.9 52.2 53.9 58.9 63.4 54.1 55.1 60.4 64.7
LWB 44.2 49.8 55.1 60.7 45.2 51.1 56.4 62.0 46.1 52.0 57.4 62.9
85
(29.44)
TCG 16.06 16.69 18.22 19.41 16.78 17.24 18.54 19.69 17.37 17.56 18.82 19.90
SHG 16.06 15.39 12.45 10.01 16.78 16.41 13.04 10.34 17.37 16.93 13.61 10.59
TC 15.89 16.52 18.05 19.24 16.60 17.06 18.37 19.51 17.19 17.39 18.64 19.72
kW 1.30 1.30 1.31 1.31 1.30 1.31 1.31 1.31 1.31 1.31 1.31 1.32
CMP 1.15 1.15 1.16 1.16 1.16 1.16 1.16 1.17 1.16 1.16 1.16 1.17
LDB 51.0 52.2 57.6 62.1 53.1 53.7 59.1 63.6 54.9 55.5 60.3 64.8
LWB 44.7 50.4 55.6 61.0 45.7 51.5 56.8 62.3 46.5 52.4 57.7 63.2
95
(35)
TCG 15.33 15.64 17.37 18.64 15.99 16.15 17.74 18.97 16.60 16.51 18.00 19.18
SHG 15.33 15.05 12.28 9.75 15.99 15.76 12.96 10.13 16.60 16.51 13.54 10.43
TC 15.16 15.47 17.20 18.46 15.81 15.98 17.57 18.80 16.43 16.34 17.83 19.00
kW 1.45 1.45 1.47 1.47 1.45 1.46 1.47 1.47 1.46 1.46 1.47 1.47
CMP 1.30 1.30 1.32 1.32 1.31 1.31 1.32 1.32 1.31 1.31 1.32 1.33
LDB 52.2 52.8 57.8 62.5 54.3 54.7 59.2 63.9 55.9 56.1 60.4 65.0
LWB 45.3 51.2 56.1 61.5 46.2 52.2 57.3 62.7 47.0 53.0 58.2 63.5
105
(40.56)
TCG 14.49 14.46 16.37 17.74 15.13 15.14 16.71 18.04 15.67 15.69 16.97 18.28
SHG 14.49 14.46 12.11 9.47 15.13 15.14 12.81 9.86 15.67 15.69 13.44 10.21
TC 14.32 14.29 16.19 17.57 14.96 14.96 16.54 17.87 15.49 15.52 16.80 18.10
kW 1.61 1.61 1.63 1.64 1.61 1.61 1.63 1.64 1.62 1.62 1.63 1.64
CMP 1.46 1.46 1.48 1.49 1.46 1.46 1.48 1.49 1.47 1.47 1.48 1.49
LDB 53.7 53.8 58.1 63.0 55.6 55.6 59.4 64.3 57.2 57.2 60.5 65.3
LWB 46.0 52.1 56.8 62.1 46.9 52.9 57.9 63.1 47.6 53.5 58.7 64.0
115
(46.11)
TCG 13.45 13.45 14.96 16.66 14.13 14.13 15.41 16.94 14.65 14.66 15.73 17.15
SHG 13.45 13.45 11.82 9.20 14.13 14.13 12.59 9.61 14.65 14.66 13.25 9.98
TC 13.27 13.27 14.79 16.48 13.95 13.96 15.24 16.77 14.48 14.48 15.56 16.97
kW 1.77 1.77 1.79 1.81 1.78 1.78 1.80 1.81 1.79 1.79 1.80 1.82
CMP 1.62 1.62 1.64 1.66 1.63 1.63 1.65 1.67 1.64 1.64 1.65 1.67
LDB 55.5 55.5 58.5 63.4 57.2 57.2 59.7 64.6 58.6 58.6 60.7 65.6
LWB 46.8 52.8 57.8 62.7 47.6 53.5 58.6 63.7 48.2 54.1 59.3 64.5
125
(51.67)
TCG 12.22 12.22 13.26 15.35 12.92 12.93 13.66 15.60 13.46 13.48 14.02 15.79
SHG 12.22 12.22 11.26 8.82 12.92 12.93 12.20 9.26 13.46 13.48 12.95 9.66
TC 12.05 12.05 13.09 15.17 12.74 12.76 13.48 15.43 13.29 13.30 13.84 15.62
kW 1.95 1.95 1.96 1.99 1.96 1.96 1.97 1.99 1.97 1.96 1.97 1.99
CMP 1.80 1.80 1.81 1.84 1.81 1.81 1.82 1.84 1.82 1.82 1.82 1.85
LDB 57.6 57.7 59.5 64.1 59.1 59.0 60.3 65.1 60.3 60.3 61.1 66.0
LWB 47.8 53.7 58.9 63.5 48.4 54.3 59.6 64.4 49.0 54.8 60.2 65.1
LEGEND
BF --- Bypass Factor
CMP --- Compressor
Edb --- Entering Dry Bulb
Ewb --- Entering Wet Bulb
k W --- To t a l Po w e r
LDB --- Leaving D ry Bulb
L W B --- L e a v i n g We t B u l b
SHG --- Gross Sensible Capacity (1000 Btu/hour)
TC --- Total Net Cooling Capacity (1000 Btu/hour)
TCG
---
Gross
Cooling
Capacity
(1000
Btu/hour)
NOTES:
1. Direct interpolation is permissible. Do not extrapolate.
2. The SHG is based on 80_F (26.67_C) edb temperature of air
entering indoor coil.
Below 80_F (26.67_C) edb, subtract (corr factor x cfm) from
SHG.
Above 80_F (26.67_C) edb, add (corr factor x cfm) to SHG.
Correction Factor = 1.10 x (1 --- BF) x (edb --- 80).
38/40MVC, MVQ
