PERFORMANCE DATA (CONT.)
COOLING CAPACITIES
38MVC(Q)024--3 / 40MVC(Q)024--3
Te m p _F(_C)
Air Entering
Condenser
(Edb)
A i r E n t e r i n g E v a p o r a t o r --- C f m / B F
584/0.04 657/0.04 759/0.05
A i r E n t e r i n g E v a p o r a t o r --- E w b ( _F)
57 62 67 72 57 62 67 72 57 62 67 72
55
(12.78)
TCG 21.41 23.09 24.52 25.73 22.21 23.60 24.95 26.13 23.21 24.19 25.43 26.63
SHG 21.41 18.42 15.56 12.83 22.21 19.37 16.10 13.17 23.21 20.61 16.74 13.53
TC 21.10 22.78 24.21 25.42 21.91 23.29 24.64 25.82 22.91 23.88 25.12 26.32
kW 1.23 1.23 1.22 1.22 1.23 1.23 1.22 1.22 1.23 1.22 1.22 1.22
CMP 1.00 1.00 1.00 1.00 1.00 1.00 1.00 0.99 1.00 1.00 0.99 0.99
LDB 46.7 51.3 55.8 60.1 49.1 53.0 57.6 61.8 51.9 55.0 59.8 63.8
LWB 42.7 48.0 53.6 59.4 43.9 49.4 55.0 60.7 45.2 50.9 56.5 62.1
65
(18.33)
TCG 20.89 22.42 23.92 25.12 21.77 22.95 24.38 25.61 22.68 23.50 24.86 26.02
SHG 20.89 18.27 15.39 12.56 21.77 19.25 15.99 12.97 22.68 20.50 16.84 13.39
TC 20.58 22.11 23.61 24.81 21.46 22.64 24.07 25.30 22.37 23.19 24.55 25.71
kW 1.38 1.39 1.39 1.39 1.39 1.39 1.39 1.39 1.39 1.39 1.39 1.39
CMP 1.15 1.16 1.16 1.16 1.16 1.16 1.16 1.16 1.16 1.16 1.16 1.16
LDB 47.4 51.5 56.0 60.5 49.7 53.2 57.8 62.1 52.5 55.1 59.6 63.9
LWB 43.1 48.4 53.9 59.7 44.2 49.8 55.3 60.9 45.5 51.2 56.7 62.4
75
(23.89)
TCG 20.21 21.66 23.21 24.61 21.15 22.15 23.67 24.95 22.04 22.71 24.13 25.32
SHG 20.21 18.13 15.13 12.37 21.15 19.10 15.83 12.75 22.04 20.44 16.61 13.19
TC 19.90 21.35 22.90 24.30 20.84 21.85 23.36 24.64 21.74 22.40 23.82 25.01
kW 1.55 1.56 1.56 1.57 1.56 1.56 1.57 1.57 1.56 1.56 1.57 1.57
CMP 1.32 1.33 1.34 1.34 1.33 1.33 1.34 1.34 1.33 1.33 1.34 1.34
LDB 48.4 51.7 56.4 60.8 50.5 53.3 58.0 62.4 53.2 55.2 59.9 64.1
LWB 43.6 49.0 54.4 60.0 44.6 50.2 55.6 61.3 45.9 51.6 57.1 62.7
85
(29.44)
TCG 19.48 20.73 22.38 23.82 20.35 21.24 22.82 24.16 21.31 21.75 23.29 24.50
SHG 19.48 17.94 14.91 12.08 20.35 18.95 15.60 12.47 21.31 20.59 16.45 12.90
TC 19.17 20.42 22.07 23.51 20.04 20.94 22.51 23.85 21.00 21.44 22.98 24.20
kW 1.72 1.74 1.75 1.76 1.73 1.74 1.75 1.76 1.74 1.74 1.75 1.76
CMP 1.49 1.51 1.52 1.53 1.50 1.51 1.52 1.53 1.51 1.52 1.53 1.53
LDB 49.5 51.9 56.7 61.2 51.6 53.5 58.2 62.7 54.1 55.0 60.0 64.5
LWB 44.1 49.6 54.9 60.4 45.1 50.8 56.1 61.6 46.3 52.1 57.4 63.0
95
(35)
TCG 18.65 19.49 21.39 22.87 19.47 20.11 21.81 23.21 20.47 20.70 22.25 23.56
SHG 18.65 17.94 14.65 11.76 19.47 19.09 15.32 12.14 20.47 19.99 16.23 12.61
TC 18.35 19.18 21.08 22.56 19.16 19.81 21.50 22.91 20.16 20.39 21.94 23.25
kW 1.91 1.92 1.94 1.95 1.92 1.93 1.94 1.96 1.93 1.94 1.95 1.96
CMP 1.68 1.69 1.71 1.73 1.69 1.70 1.72 1.73 1.70 1.71 1.72 1.73
LDB 50.7 51.9 57.1 61.7 52.7 53.3 58.6 63.1 55.1 55.7 60.3 64.8
LWB 44.7 50.4 55.5 60.9 45.6 51.4 56.6 62.1 46.7 52.6 57.9 63.4
105
(40.56)
TCG 17.81 18.14 20.24 21.73 18.51 18.71 20.65 22.09 19.45 19.31 21.06 22.41
SHG 17.81 17.46 14.30 11.33 18.51 18.23 15.04 11.77 19.45 19.31 15.98 12.26
TC 17.50 17.83 19.94 21.42 18.20 18.40 20.34 21.78 19.14 19.01 20.76 22.10
kW 2.11 2.11 2.14 2.16 2.12 2.12 2.15 2.16 2.13 2.13 2.15 2.17
CMP 1.88 1.88 1.91 1.93 1.89 1.89 1.92 1.94 1.91 1.90 1.92 1.94
LDB 52.0 52.5 57.5 62.3 54.0 54.4 58.9 63.6 56.3 56.4 60.5 65.2
LWB 45.3 51.3 56.1 61.5 46.2 52.2 57.2 62.6 47.3 53.3 58.4 63.8
115
(46.11)
TCG 16.73 16.67 18.93 20.40 17.42 17.43 19.28 20.74 18.31 18.33 19.67 21.05
SHG 16.73 16.67 13.90 10.86 17.42 17.43 14.66 11.30 18.31 18.33 15.64 11.81
TC 16.42 16.37 18.62 20.09 17.11 17.12 18.98 20.44 18.00 18.02 19.36 20.74
kW 2.32 2.32 2.35 2.37 2.33 2.33 2.36 2.38 2.34 2.34 2.36 2.38
CMP 2.09 2.09 2.12 2.14 2.10 2.10 2.13 2.15 2.11 2.11 2.13 2.15
LDB 53.6 53.7 58.1 63.0 55.5 55.5 59.4 64.2 57.6 57.6 60.9 65.7
LWB 46.1 52.2 56.9 62.2 46.9 52.9 57.9 63.2 47.9 53.8 59.0 64.4
125
(51.67)
TCG 15.61 15.61 17.39 18.89 16.27 16.27 17.73 19.19 17.06 17.09 18.07 19.47
SHG 15.61 15.61 13.42 10.33 16.27 16.27 14.19 10.77 17.06 17.09 15.18 11.29
TC 15.30 15.30 17.08 18.58 15.96 15.96 17.43 18.88 16.75 16.78 17.77 19.16
kW 2.53 2.53 2.56 2.59 2.54 2.54 2.57 2.59 2.56 2.56 2.57 2.60
CMP 2.30 2.30 2.33 2.36 2.32 2.32 2.34 2.37 2.33 2.33 2.35 2.37
LDB 55.3 55.3 58.8 63.8 57.0 57.0 60.0 64.9 59.1 59.0 61.4 66.3
LWB 46.9 52.9 57.8 63.0 47.6 53.6 58.7 63.9 48.5 54.4 59.7 65.0
LEGEND
BF --- Bypass Factor
CMP --- Compressor
Edb --- Entering Dry Bulb
Ewb --- Entering Wet Bulb
k W --- To t a l Po w e r
LDB --- Leaving D ry Bulb
L W B --- L e a v i n g We t B u l b
SHG --- Gross Sensible Capacity (1000 Btu/hour)
TC --- Total Net Cool ing Capacity (1000 Btu/hour)
TCG --- Gross Cooling Capacity (1000 Btu/hour)
NOTES:
1. Direct interpolation is permissible. Do not extrapolate.
2. The SHG is based on 80_F (26.67_C) edb temperature of air
entering indoor coil.
Below 80_F (26.67_C) edb, subtract (corr factor x cfm) from SHG.
Above 80_F (26.67_C) edb, add (corr factor x cfm) to SHG.
Correction Factor = 1.10 x (1 --- BF) x (edb --- 80).
38/40MVC, MVQ
