Carrier 40MVC User Manual

15
PERFORMANCE DATA (CONT.)
INSTANTANEOUS AND INTEGRATED HEATING RATINGS
38MVQ009--1 / 40MVQ009--1
Air Temperature
Entering Indoor
Unit _F(_C)
Indoor
Airflow
(CFM)
L --- M --- H
Item
Air Temperature Entering Outdoor Coil --- DB/WB _F(_C)
57/53 (13.89/11.67) 47/43 (8.33/6.11) 37/33 (2.78/0.56) 27/23 (---2.78/---5) 17/13 (---8.33/---10.56)
Instant. Integrated Instant. Integrated Instant. Integrated Instant. Integrated Instant. Integrated
Rating Rating Rating Rating Rating Rating Rating Rating Rating Rating
55 (12.78)
214
Cap 10.99 10.99 9.55 9.55 8.13 7.40 6.80 6.04 5.55 5.06
kW 0.83 0.77 0.71 0.66 0.61
284
Cap 11.39 11.39 9.97 9.97 8.47 7.70 7.08 6.29 5.78 5.27
kW 0.74 0.71 0.66 0.62 0.58
346
Cap 11.57 11.57 10.12 10.12 8.65 7.87 7.24 6.43 5.91 5.39
kW 0.69 0.66 0.63 0.59 0.57
60 (15.56)
214
Cap 10.75 10.75 9.31 9.31 7.93 7.21 6.60 5.86 5.36 4.88
kW 0.87 0.80 0.74 0.68 0.64
284
Cap 11.18 11.18 9.78 9.78 8.27 7.53 6.89 6.12 5.58 5.09
kW 0.78 0.74 0.69 0.64 0.61
346
Cap 11.36 11.36 9.93 9.93 8.46 7.70 7.05 6.26 5.71 5.21
kW 0.73 0.70 0.66 0.62 0.59
65 (18.33)
214
Cap 10.51 10.51 9.11 9.11 7.72 7.02 6.39 5.67 5.15 4.69
kW 0.90 0.84 0.77 0.71 0.66
284
Cap 10.96 10.96 9.52 9.52 8.07 7.34 6.68 5.93 5.38 4.91
kW 0.82 0.77 0.72 0.67 0.64
346
Cap 11.14 11.14 9.74 9.74 8.26 7.52 6.85 6.08 5.51 5.02
kW 0.77 0.73 0.69 0.65 0.62
70 (21.11)
214
Cap 10.28 10.28 8.88 8.88 7.50 6.83 6.18 5.48 4.93 4.50
kW 0.94 0.87 0.80 0.74 0.69
284
Cap 10.74 10.74 9.31 9.31 7.86 7.15 6.47 5.75 5.16 4.71
kW 0.86 0.81 0.75 0.70 0.66
346
Cap 10.93 10.93 9.56 9.56 8.06 7.33 6.63 5.89 5.30 4.83
kW 0.81 0.77 0.72 0.68 0.65
75 (23.89)
214
Cap 10.04 8.66 8.64 8.64 7.28 8.66 5.96 5.29 4.71 4.29
kW 0.97 0.90 0.83 0.77 0.71
284
Cap 10.51 8.89 9.09 9.09 7.64 8.89 6.25 5.55 4.94 4.51
kW 0.89 0.84 0.78 0.73 0.69
346
Cap 10.71 10.71 9.32 9.32 7.84 7.14 6.42 5.70 5.08 4.63
kW 0.84 0.80 0.75 0.71 0.67
80 (26.67)
214
Cap 9.80 9.80 8.40 8.40 7.06 6.42 5.74 5.09 4.47 4.08
kW 1.01 0.93 0.86 0.80 0.74
284
Cap 10.27 10.27 8.85 8.85 7.42 6.75 6.03 5.35 4.71 4.30
kW 0.93 0.87 0.81 0.76 0.72
346
Cap 10.49 10.49 9.11 9.11 7.62 6.94 6.19 5.50 4.84 0.97
kW 0.88 0.84 0.78 0.74 0.70
Indicates Rating Condition (* Integrated Capacity) Indicates Integrated Rating
Cap --- Heating Capacity (100 Btuh), Includes indoor f an motor heat
kW --- Total Power Input, includes compressor motor power input, outdoor fan motor power input, and indoor fan motor power input
Note: Integrated Capacity is maximum (instantaneous ) capacity less the effect of frost on the outdoor coil and the heat to defrost it.
38/40MVC, MVQ
