APPENDIX A — CCN TABLES (cont)
OPTIONS1 (Option Configurations)
IAQ (Indoor Air Quality Configurations)
SEN_CAL (Space Temperature Sensor Calibration)
DESCRIPTION STATUS DEFAULT UNITS POINT
Startup Delay (seconds)
0 – 600 30 sec STARTDLY
Unit Control Type
1 = AutoSelect
2 = Thermostat
3 = Space Sensor
1 CTL_TYPE
Thermostat Control Type
0 = Adaptive
1 = 1 Stage Y1
2 = 2 Stage Y1
0STATTYPE
Fan On When Occupied
Yes/No Yes OCC_FAN
Shut Down on IDF Failure
Yes/No Yes FATALFAN
Economizer Equipped Unit
Yes/No Yes ECONO
Fan Status Switch
0 = Not Installed
1 = Normally Open
2 = Normally Closed
0FANSTCFG
Filter Status Switch
0 = Not Installed
1 = Normally Open
2 = Normally Closed
0: No FIOP
1: FIOP
FILSTCFG
Fire Shutdown Switch
0 = Not Installed
1 = Normally Open
2 = Normally Closed
0: No FIOP
2: FIOP
SHTDNCFG
Remote Occupancy Switch
0 = Not Installed
1 = Normally Open
2 = Normally Closed
0 REMOCCFG
DESCRIPTION STATUS DEFAULT UNITS POINT
Minimum IAQ Position
0 – 30 10 % IAQMINP
Economizer Min Position
0 – 100 30 % ECONOMIN
AQ Differential Low
0 – 1000 100 DAQ_LOW
AQ Differential High
100 – 2000 700 DAQ_HIGH
IAQ Sensor Value at 4mA
0 – 5000 0 IAQ_4MA
IAQ Sensor Value at 20mA
0 – 5000 2000 IAQ_20MA
OAQ Sensor Value at 4mA
0 – 5000 0 OAQ_4MA
OAQ Sensor Value at 20mA
0 – 5000 2000 OAQ_20MA
OAQ Lockout Value
600 OAQLOCK
DESCRIPTION STATUS DEFAULT UNITS POINT
Space Temperature Calibration
–30 – 130 F SPT_CAL
Space Temperature Trim
–30 – 30 0 ^F SPT_OFF
