Carrier 48HG024 - Page 46

46
APPENDIX A — CCN TABLES (cont)
ECONOCFG (Economizer Configurations)
SET_PNT (Unit Set Points)
DESCRIPTION STATUS DEFAULT UNITS POINT
Economizer Control Board Installed
Yes/No Yes ECB_ECON
Economizer Min Position
0 – 100 30 % ECONOMIN
Econ High Temp Lockout
55 – 75 65 dF OATLECLH
Econ Low Temp Lockout
0 – 50 30 dF OATLECLL
Unoccupied Free Cooling
Enable/Disable FC_ENABL
Power Exhaust Control
Enable/Disable Disable : NO FIOP
Enable: FIOP
PE_ENABL
PE Stage1 Econo Position
0 – 100 25 % PE1_POS
PE Stage2 Econo Position
0 – 100 75 % PE2_POS
Enthalpy Switch
0 = Not Installed
1 = Normally Open
2 = Normally Closed
0 ENTHLCFG
Economizer Travel Time
5 – 300 150 sec ECONOTRV
Bottom Stage Max Econmzr
0 – 100 50 % ECONMAXB
Middle Stage Max Econmzr
0 – 100 25 % ECONMAXM
Top Stage Max Econmzr
0 – 100 0 % ECONMAXT
Economizer PID Deadband
0 – 25 3 % ECONBAND
Economizer PID – kP
0.0 – 99.9 2.5 ECONO_P
Economizer PID – kI
0.0 – 99.9 .12 ECONO_I
Economizer PID – kD
0.0 – 99.9 1 ECONO_D
Economizer PID – rate
0.0 – 99.9 15.0 sec ECONO_DT
DESCRIPTION STATUS DEFAULT UNITS POINT
Occupied Cool Set point
55 – 80 78 dF OCSP
Occupied Heat Set point
55 – 80 68 dF OHSP
Unoccupied Cool Set point
75 – 95 85 dF UCSP
Unoccupied Heat Set point
40 – 80 60 dF HCSP
Heat-Cool Set point Gap
2 – 10 5 ^F HCSP_GAP
Heating Lockout Temp
55 – 90 75 dF OATLHEAT
Compressor Lockout Temp
0 – 75 0 dF OATLCOMP
Econ High Temp Lockout
40 – 75 65 dF OATLECLH
Econ Low Temp Lockout
0 – 50 0 dF OATLECLL
Minimum SAT Upper Level
35 – 65 58 dF SATMIN_H
Minimum SAT Lower Level
35 – 65 48 dF SATMIN_L
Low Cool SAT Set point
55 – 75 65 dF LCSASP
High Cool SAT Set point
50 – 70 55 dF HCSASP
