Carrier 50FC A05 Series User Manual

72
APPENDIX C — FAN PERFORMANCE
50FC-M07 THREE PHASE – MEDIUM STATIC — 6 TON VERTICAL SUPPLY (RPM - VDC)
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
RPM Vdc RPM Vdc RPM Vdc RPM Vdc RPM Vdc
1800
1423 5.6 1550 6.1 1682 6.6 1820 7.2 1955 7.7
1950
1521 6.0 1638 6.5 1758 6.9 1883 7.4 2011 7.9
2100
1620 6.4 1730 6.8 1839 7.3 1953 7.7 2071 8.2
2250
1720 6.8 1824 7.2 1924 7.6 2029 8.0 2137 8.4
2400
1820 7.2 1919 7.6 2013 8.0 2109 8.3 2209 8.7
2550
1921 7.6 2016 8.0 2105 8.3 2194 8.7 2286 9.0
2700
2022 8.0 2113 8.4 2198 8.7 2282 9.0 2368 9.4
2850
2123 8.4 2212 8.7 2293 9.1 2373 9.4 2453 9.7
3000
2225 8.8 2311 9.1 2389 9.4 2465 9.7 — —
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
RPM Vdc RPM Vdc RPM Vdc RPM Vdc RPM Vdc
1800
2079 8.2 2192 8.7 2296 9.1 2393 9.5 2485 9.8
1950
2133 8.4 2247 8.9 2353 9.3 2451 9.7 — —
2100
2189 8.7 2301 9.1 2408 9.5 2507 9.9 — —
2250
2248 8.9 2357 9.3 2462 9.7————
2400
2312 9.1 2416 9.5 2517 9.9————
2550
2381 9.4 2479 9.8——————
2700
2456 9.7————————
2850 ——————————
3000 ——————————
Medium Static 1423-2530 RPM
50FC-M07 THREE PHASE – HIGH STATIC — 6 TON VERTICAL SUPPLY (RPM - VDC)
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
RPM Vdc RPM Vdc RPM Vdc RPM Vdc RPM Vdc
1800
1423 5.0 1550 5.5 1682 5.9 1820 6.4 1955 6.9
1950
1521 5.4 1638 5.8 1758 6.2 1883 6.6 2011 7.1
2100
1620 5.7 1730 6.1 1839 6.5 1953 6.9 2071 7.3
2250
1720 6.1 1824 6.4 1924 6.8 2029 7.2 2137 7.5
2400
1820 6.4 1919 6.8 2013 7.1 2109 7.4 2209 7.8
2550
1921 6.8 2016 7.1 2105 7.4 2194 7.7 2286 8.1
2700
2022 7.1 2113 7.5 2198 7.8 2282 8.0 2368 8.3
2850
2123 7.5 2212 7.8 2293 8.1 2373 8.4 2453 8.6
3000
2225 7.8 2311 8.1 2389 8.4 2465 8.7 2541 9.0
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
RPM Vdc RPM Vdc RPM Vdc RPM Vdc RPM Vdc
1800
2079 7.3 2192 7.7 2296 8.1 2393 8.4 2485 8.8
1950
2133 7.5 2247 7.9 2353 8.3 2451 8.6 2543 9.0
2100
2189 7.7 2301 8.1 2408 8.5 2507 8.8 2601 9.2
2250
2248 7.9 2357 8.3 2462 8.7 2562 9.0 2656 9.4
2400
2312 8.2 2416 8.5 2517 8.9 2616 9.2 2711 9.6
2550
2381 8.4 2479 8.7 2576 9.1 2672 9.4 2765 9.7
2700
2456 8.7 2546 9.0 2638 9.3 2730 9.6 2821 9.9
2850
2535 8.9 2619 9.2 2705 9.5 2793 9.8 ——
3000
2618 9.2 2696 9.5 2777 9.8 ————
High Static 1423-2836 RPM
