Carrier 50FC A05 Series User Manual

83
APPENDIX C — FAN PERFORMANCE
50FC-A06 THREE PHASE — 5 TON HORIZONTAL SUPPLY (RPM - BHP)
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1500
1267 0.21 1442 0.31 1612 0.44 1770 0.58 1916 0.73
1625
1345 0.25 1506 0.35 1666 0.48 1818 0.62 1960 0.78
1750
1425 0.30 1574 0.40 1723 0.53 1869 0.68 2006 0.84
1875
1507 0.35 1644 0.46 1785 0.59 1923 0.73 2056 0.90
2000
1590 0.41 1718 0.52 1849 0.65 1980 0.80 2108 0.96
2125
1674 0.48 1794 0.59 1917 0.72 2041 0.87 2163 1.04
2250
1759 0.56 1872 0.67 1987 0.80 2104 0.95 2221 1.12
2375
1845 0.64 1951 0.76 2060 0.89 2171 1.05 2281 1.21
2500
1932 0.74 2032 0.86 2135 0.99 2239 1.15 2345 1.32
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1500
2051 0.90 2177 1.08 2296 1.26 2408 1.46 2515 1.66
1625
2093 0.95 2217 1.13 2334 1.32 2445 1.52 2551 1.72
1750
2136 1.01 2259 1.19 2374 1.38 2484 1.59 2589 1.80
1875
2182 1.07 2302 1.26 2416 1.45 2524 1.66 2628 1.87
2000
2230 1.14 2347 1.33 2459 1.53 2566 1.74 2669 1.96
2125
2281 1.22 2395 1.41 2505 1.61 2610 1.83 2711 2.05
2250
2334 1.30 2445 1.50 2552 1.70 2655 1.92 2754 2.14
2375
2391 1.40 2497 1.59 2601 1.80 2702 2.02 2800 2.25
2500
2449 1.50 2552 1.70 2653 1.91 2751 2.13 ——
Standard Static 1267-2150 RPM, 1.06 Max BHP
Medium Static 1267-2390 RPM, 1.44 Max BHP
High Static 1267-2836 RPM, 2.43 Max BHP
50FC-A06 THREE PHASE – STANDARD STATIC — 5 TON HORIZONTAL SUPPLY (RPM - VDC)
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
0.2 0.4 0.6 0.8 1.0
RPM Vdc RPM Vdc RPM Vdc RPM Vdc RPM Vdc
1500
1267 5.9 1442 6.7 1612 7.5 1770 8.2 1916 8.9
1625
1345 6.3 1506 7.0 1666 7.7 1818 8.5 1960 9.1
1750
1425 6.6 1574 7.3 1723 8.0 1869 8.7 2006 9.3
1875
1507 7.0 1644 7.6 1785 8.3 1923 8.9 2056 9.6
2000
1590 7.4 1719 8.0 1849 8.6 1980 9.2 2108 9.8
2125
1674 7.8 1794 8.3 1917 8.9 2041 9.5 — —
2250
1760 8.2 1872 8.7 1987 9.2 2104 9.8 — —
2375
1845 8.6 1951 9.1 2060 9.6 — — — —
2500
1932 9.0 2032 9.5 2135 9.9 — — — —
CFM
AVAILABLE EXTERNAL STATIC PRESSURE (in. wg)
1.2 1.4 1.6 1.8 2.0
RPM Vdc RPM Vdc RPM Vdc RPM Vdc RPM Vdc
1500
2051 9.5————————
1625
2093 9.7————————
1750
2136 9.9————————
1875 ——————————
2000 ——————————
2125 ——————————
2250 ——————————
2375 ——————————
2500 ——————————
Standard Static 1267-2150 RPM
