75
APPENDIX A: SystemVut Controller Display
Service Main Menu Layout
DISPLAY TEXT EXPA NDED DISPLAY TEXT VALUES UNITS WRITE STATUS POINT
SERVICE Service Menu
UNIT TEST S Unit Tests Menu
TEST MODE ServiceTestModeEnable On/Off Command
SERVICE TEST Service Test Menu
INDEPENDENTS INDEPENDENT TEST MENU
ECON POS TEST Economizer Position Test 0 to 100 % Command S_DAMPER
BUMP COMP A1 TEST Compressor Bump A1 Test On/Off Command S_BMPA1
RH DIS VALVE TEST Rht Dischg Valve Rly Tst On/Off Command S_RDV_A
RH LIQ VALVE TEST Reheat Liq Valv Rly Test On/Off Command S_RLV_A
CL LIQ VALVE TEST Cooling Liq Valv Test On/Off Command S_CLV_A
CCH RELAY 1 TEST Crankcase Heater 1 test On/Off Command S_CCHR1
ALARM RELAY TEST Alarm Output Relay Test On/Off Command S_ALARM
PE1 RELAY TEST Power Exhaust 1 T est On/Off Command S_PE_1
PE2 RELAY TEST Power Exhaust 2 T est On/Off Command S_PE_2
2POS/ERV RLY TEST 2Position/ERV Relay Test On/Off Command S_ERV2P
FAN TESTS Indoor and Outdoor Fan tests Menu
IDF SPEED TEST Indoor Fan Speed Test 0 to 100 % Command S_IDFSPD
CONVERTED IDF RPM Converted IDF Speed 0 to 5000 RPM IFRPMTST
IDF MANUAL TRANS IDF Manual Transition Ye s/No Command S_IDFTRN
COOL TESTS Cooling Test Menu
COOL A1 TEST Cooling W/Comp.A1 Test On/Off Command S_COOLA1
CIR A LOADER TEST Cooling W/Comp.ALD Test On/Off Command S_COLALD
IDF SPEED TEST Indoor Fan Speed Test 0 to 100 % Command S_IDFSPD
ODF RELAY TEST ODF Speed Relay Test On/Off Command S_OFRSPD
HUMIDIMIZER TEST Humidimizer Level Test 0=Off,
1=Subcool,
2=Reheat
Command S_HMZLEV
HEAT TESTS Heating Test Menu
HEAT 1 TEST Heating Stage 1 Test On/Off Command S_HEAT1
HEAT 2 TEST Heating Stage 2 Test On/Off Command S_HEAT2
IDF SPEED TEST Indoor Fan Speed Test 0 to 100 % Command S_IDFSPD
AUTOMATIC TEST Automatic Test Menu
AUTO INDP TEST AUTO INDEPENDENT TEST Yes/No Command AUTOINDP
AUTO COOL TEST RUN AUTO COOLING TEST Yes/No Command AUTOCOOL
AUTO HEAT TEST RUN AUTO HEATING TEST Yes/No Command AUTOHEAT
AUTO SYSTEM TEST RUN AUTO SYSTEM TEST Yes/No Command AUTOSYS
UNIT INFORMATION Unit Information Menu
MODEL # Equipment Model number xxxxxxxxxxxxxxxxxx Command EQ_MOD
SERIAL # Equipment Serial number xxxxxxxxxx Command EQ_SER
VERSIONS Versions Menu
MAIN APP Application SW Version CESR131656--- 01--- xx FW_CESR
BOOTLOADER Bootloader SW Version CESR131659--- 01--- 03 BL_CESR
USER MEASURED DATA User Measured Data Menu
SUPPLY VOLTAGE L1 Supply Voltage Leg 1 0 to 700 V Command L1VOLTS
SUPPLY VOLTAGE L2 Supply Voltage Leg 2 0 to 700 V Command L2VOLTS
SUPPLY VOLTAGE L3 Supply Voltage Leg 3 0 to 700 V Command L3VOLTS
COMP A1 AMPS L1 Comp A1 Amps Leg 1 0 to 100 A Command CA1L1_A
COMP A1 AMPS L2 Comp A1 Amps Leg 2 0 to 100 A Command CA1L2_A
COMP A1 AMPS L3 Comp A1 Amps Leg 3 0 to 100 A Command CA1L3_A
E.HEAT AMPS L1 Elec. H eat Amps Leg 1 0 to 100 A Command EHTL1_A
E.HEAT AMPS L2 Elec. H eat Amps Leg 2 0 to 100 A Command EHTL2_A
E.HEAT AMPS L3 Elec. H eat Amps Leg 3 0 to 100 A Command EHTL3_A
GAS SUPPLY TYPE Gas Supply Type 0=NATURAL,
1=LP
Command GASTYPE
GAS INLET PRESS GAS INLET PRESSURE 0to20 Hg Command GASPRESS
STAGE 1 GAS PRESS STAGE 1 GAS PRESSURE 0to20 Hg Command HT1PRESS
STAGE 2 GAS PRESS STAGE 2 GAS PRESSURE 0to20 Hg Command HT2PRESS
CONTINUE? Start Diag Report Yes/No Command GO_DIAG
RUN HOURS & CYCLES Run Hours & Cycles Menu
RUN HOURS DATA MENU Run hours menu
2POS/ERV RUN HOUR 2Position/ERV Run Hours xxxxxx.x hrs HR_ERV2P
COMP A1 RUN HOURS Compressor A1 Run Hours xxxxxx.x hrs HR_A1
CMP ALD RUN HOURS CMP A1 Loader Run Hours xxxxxx.x hrs HR_ALDR
ALM RELAY HOURS Alarm Relay Run Hours xxxxxx.x hrs HR_ALM
CCH RELAY HOURS CCH1 Relay Run Hours xxxxxx.x hrs HR_CCHR1
