76
APPENDIX A: SystemVut Controller Display
Service Main Menu Layout (cont)
DISPLAY TEXT EXPA NDED DISPLAY TEXT VALUES UNITS WRITE STATUS POINT
RUN HOURS & CYCLES (cont) Run Hours & Cycles Menu
ECON RUN HOURS Econ Damper Run Hours xxxxxx.x hrs HR_DAMP
FULL LOAD HOURS Unit Full Load Run Hours xxxxxx.x hrs HR_FLOAD
FREE COOL HOURS Free Cooling Run Hours xxxxxx.x hrs HR_FREEC
HEAT 1 RUN HOURS Heat Stage 1 Run Hours xxxxxx.x hrs HR_HTR_1
HEAT 2 RUN HOURS Heat Stage 2 Run Hours xxxxxx.x hrs HR_HTR_2
IDF RUN HOURS Indoor Fan Run Hours xxxxxx.x hrs HR_IDF
MAX IDF RUN HOURS Max Fan Speed Run Hours xxxxxx.x hrs HR_MAXF
ODF RELAY HOURS ODF Relay Run Hours xxxxxx.x hrs HR_OFR
PE1 RELAY HOURS Power Exhaust1 Run Hours xxxxxx.x hrs HR_PE_1
PE2 RELAY HOURS Power Exhaust2 Run Hours xxxxxx.x hrs HR_PE_2
RDV_A RUN HOURS RDV_A Run Hours xxxxxx.x hrs HR_RDV_A
RLV_A RUN HOURS RL V_A Run Hours xxxxxx.x hrs HR_RLV_A
CLV_A RUN HOURS CLV_A Run Hours xxxxxx.x hrs HR_CLV_A
SUBCOOLING HOURS Reheat level 1 Run Hrs xxxxxx.x hrs HR_RQHL1
HOT GAS RH HOURS Reheat level 2 Run Hrs xxxxxx.x hrs HR_RQHL2
TEST MODE HOURS Service Test Run Hours xxxxxx.x hrs HR_STEST
VENT IDF HOURS Vent IDF Run Hours xxxxxx.x hrs HR_VENTF
START COUNT DAT A MENU Start Counts menu
2POS/ERV STARTS 2Position/ERV Starts xxxxxx ST_ERV2P
COMP A1 STARTS Compressor A1 Starts xxxxxx ST_A1
CMP ALD STARTS CMP A1 Loader Starts xxxxxx ST_ALDR
ALM RELAY STARTS Alarm Relay Starts xxxxxx ST_ALM
ALM RESET COUNTS Alarm Reset Count s xxxxxx ST_ALRST
CCH RELAY STARTS CCH1 Relay Starts xxxxxx ST_CCHR1
DAMPER ST ARTS Economizer Damper Starts xxxxxx ST_DAMP
FULL LOAD STARTS Unit Full Load Starts xxxxxx ST_FLOAD
FREE COOL STARTS Free Cooling Starts xxxxxx S T _FREEC
HEAT 1 STARTS Heat Stage 1 Starts xxxxxx ST_HTR_1
HEAT 2 STARTS Heat Stage 2 Starts xxxxxx ST_HTR_2
IDF STARTS Indoor Fan Starts xxxxxx ST_IDF
MAX IDF SPD START Max IDF Speed Starts xxxxxx ST_MAXF
ODF RELAY STARTS ODF Relay Starts xxxxxx ST_OFR
PE1 RELAY STARTS Power Exhaust 1 Starts xxxxxx ST_PE_1
PE2 RELAY STARTS Power Exhaust 2 Starts xxxxxx ST_PE_2
POR COUNT Power Cycle Counts xxxxxx ST_POR
RDV A STARTS RDV_A Starts xxxxxx ST_RDV_A
RLV_A STARTS RLV_A Starts xxxxxx ST_RLV_A
CLV_A STARTS CLV_A Starts xxxxxx ST_CLV_A
SUBCOOL STARTS Reheat level 1 Starts xxxxxx ST_RQHL1
HOT GAS RH STARTS Reheat level 2 Starts xxxxxx ST_RQHL2
TEST MODE STARTS Service Test Starts xxxxxx ST_STEST
VENT FAN STARTS Ventilation Fan Starts xxxxxx ST_VENTF
RESET COUNTS MENU Reset Counts menu
2POS/ERV RESETS 2Position/ERV ResetCount xxxxxx RS_ERV2P
COMP A1 RESET QTY Comp A1 Resets Count xxxxxx RS_A1
CMP ALD RESET QTY A1 Loader Resets Count xxxxxx RS_ALDR
ALMRLYRESETQTY Alarm Relay Resets Count xxxxxx RS_ALM
ALM RESET RESETS Alarm Reset Resets Count xxxxxx RS_ALRST
CCH RELAY RESETS CCH1 Relay Resets Count xxxxxx RS_CCHR1
DAMPER RESET QTY Econ Damper Resets Count xxxxxx RS_DAMP
FULL LOAD RESETS Full Load Resets Count xxxxxx RS_FLOAD
FREE COOL RESETS Free Cooling Reset Count xxxxxx RS_FREEC
HEAT 1 RESET QTY Heat Stage 1 Reset Count xxxxxx RS_HTR_1
HEAT 2 RESET QTY Heat Stage 2 Reset Count xxxxxx RS_HTR_2
