GUSSET
SCREWS
GUSSET
SCREWS
PARTITION GUSSET
CONDENSER
ORIFICE (PLASTIC)
GUSSET
CONDENSER
ORIFICE
CAPTIVE
SCREWS (2)
CAPTIVE
SCREWS (2)
FIGURE 12 — GUSSET REMOVAL
FIGURE 13 — LOCATION OF CAPTIVE SCREWS
ON CONDENSER ORIFICE
FIGURE 14 — PRYING CONDENSER ORIFICE
AWAY FROM TUBE SHEET
FIGURE 15 — REMOVING TOP OF
CONDENSER ORIFICE
