Carrier 52C Series User Manual

15
ACCESSORIES
*Custom colors are also available.
ACCESSORY FORM NUMBER PART NUMBER DESCRIPTION
Wall Sleeves 52S-48SI WALL-SLEEVE-1PK Non-Insulated Polymer Wall Sleeve, 1 per pack
WALL-SLEEVE-9PK Non-Insulated Polymer Wall Sleeve, 9 per pack
SLEEVE-INSUL-1PK Insulated Polymer Wall Sleeve, 1 per pack
52S-50SI SLEEVE-STEEL-1PK Insulated Metal Wall Sleeve, 1 per pack
52S-49SI SLEEVE-EXT24-1PK Extended Metal Wall Sleeve for Deep Wall Applications (24 in. deep), 1 per pack
SLEEVE-EXT26-1PK Extended Metal Wall Sleeve for Deep Wall Applications (26 in. deep), 1 per pack
SLEEVE-EXT28-1PK Extended Metal Wall Sleeve for Deep Wall Applications (28 in. deep), 1 per pack
SLEEVE-MOLDING Molding kit to trim the wall sleeve to the wall
52C,P-26SI FR-SLEEVE-EXT Friedrich wall sleeve extension to retrofit Carrier PTAC unit into Friedrich 11
1
/
2
″deep
(T Series) wall sleeve. 1 per pack
Exterior Grilles* 52S-59SI GRILLE-ALU-STAMP Stamped Aluminum Exterior Grille, Clear Finish
52S-65SI
GRILLE-PLA-BROWN Polymer Architectural Rear Grille, Brown
GRILLE-PLA-BEIGE Polymer Architectural Rear Grille, Beige
52S-60SI GRILLE-ALU-CLEAR Aluminum Architectural Exterior Grille, Clear Finish
GRILLE-ALU-WHITE Aluminum Architectural Exterior Grille, White
GRILLE-ALU-BRONZ Aluminum Architectural Exterior Grille, Light Bronze
GRILLE-ALU-MBRNZ Aluminum Architectural Exterior Grille, Medium Bronze
GRILLE-ALU-BROWN Aluminum Architectural Exterior Grille, Brown (Dark Bronze)
GRILLE-ALU-BEIGE Aluminum Architectural Exterior Grille, Beige
GRILLE-ALU-ALPIN Aluminum Architectural Exterior Grille, Alpine (matches Carrier Wall Sleeve)
GRILLE-ALU-PEACH Aluminum Architectural Exterior Grille, Peach
GRILLE-ALU-MELON Aluminum Architectural Exterior Grille, Melon
GRILLE-ALU-LGREY Aluminum Architectural Exterior Grille, Light Grey
GRILLE-ALU-SGREY Aluminum Architectural Exterior Grille, Slate Gray
GRILLE-ALU-RDBRK Aluminum Architectural Exterior Grille, Red Brick
GRILLE-ALU-BLUE Aluminum Architectural Exterior Grille, Blue
GRILLE-ALU-GREEN Aluminum Architectural Exterior Grille, Green
52C,P-31SI BAFFLE-KIT-1PK Ensures good air seal and prevents air recirculation when Carrier sleeve is used with a non-Carrier grille.
Subbase 52C,P-1SI SUBBASE-NON-ELEC Non-electrical Subbase
52C,P-2SI SUBBASE-230V-15A Electrical subbase with factory-installed 208/230V, 15 amp receptacle
SUBBASE-230V-20A Electrical subbase with factory-installed 208/230V, 20 amp receptacle
SUBBASE-230V-30A Electrical subbase with factory-installed 208/230V, 30 amp receptacle
52C,P-17SI SUBBASE-265V-15A Electrical subbase with factory-installed 265V, 15 amp receptacle
SUBBASE-265V-20A Electrical subbase with factory-installed 265V, 20 amp receptacle
SUBBASE-265V-30A Electrical subbase with factory-installed 265V, 30 amp receptacle
52C,P-3SI SUBBASE-HARDWIRE Electrical subbase with factory-installed hardwire kit (230/208V and 265V)
Subbase
Field-Installed
Kits
52C,P-4SI SUBBASE-SWITCH Field-Installable Switch kit for an electrical subbase
52C,P-5SI SUBBASE-FUSE-15A Field-Installed Fuse Kit (15 amp) for electrical subbase
SUBBASE-FUSE-20A Field-Installed Fuse Kit (20 amp) for electrical subbase
SUBBASE-FUSE-30A Field-Installed Fuse Kit (30 amp) for electrical subbase
Electrical
Connections
52C,P-11SI HARDWIRE-KIT-1PK Permanent power connection to the unit (includes 36″of flexible conduit and unit-mounted
connector, 230/208V and 265V) 1 per pack
52C,P-19SI CONDUIT-INTF-4PK Interface kit for field-supplied conduit to provide permanent power connection
(230/208V and 265V) to the unit. Kit includes Molex connector for easy connect/disconnect.
4 per pack
Condensate
Drain Kit
52S-53SI DRAIN-KIT-4PK Attaches to wall sleeve for controlled internal or external disposal of condensate 4 per pack
Wall
Thermostats
N/A HH01AD045 Electro-mechanical Wall Thermostat (Heat/Cool and Heat Pump)
TSTATCCBPC01-B Value Series Electronic Thermostat w/Digital display (Heat/Cool Models)
TSTATCCBPH01-B Value Series Electronic Thermostat w/Digital display (Heat Pump Models)
TSTATCCPAC01-B 7-Day Programmable Electronic Thermostat (Heat/Cool Models)
TSTATCCPHP01-B 7-Day Programmable Electronic Thermostat (Heat Pump Models)
Wall Thermostat
Interface
Retrofit Kit
52C,P-30SI RC-FIELDKIT230HC Field-installed wall thermostat retrofit kit to convert a standard 230V Heat/Cool unit to an
RC unit. Wall thermostat sold separately (can be used to convert a cool only unit to RC).
RC-FIELDKIT230HP Field-installed wall thermostat retrofit kit to convert a standard 230V Heat Pump unit to an
RC unit. Wall thermostat sold separately.
RC-FIELDKIT265HC Field-installed wall thermostat retrofit kit to convert a standard 265V Heat/Cool unit to an
RC unit. Wall thermostat sold separately (can be used to convert a cool only unit to RC).
RC-FIELDKIT265HP Field-installed wall thermostat retrofit kit to convert a standard 265V Heat Pump unit to a
RC unit. Wall thermostat sold separately.
52C,P-34SI 2SPEED-TSTAT-KIT Field-installed automatic heat/cool changeover thermostat with 2-speed fan control at thermostat.
N/A TSTAT-COVER-6X7 Clear plastic locking thermostat cover prevents unauthorized access to thermostat.
Cover for use with non-programmable and electro-mechanical thermostats.
Outside dimensions: 6
1
/
2
″ x 7
1
/
2
″ x 2
15
/
16
″. 1 per pack
N/A TSTAT-COVER-7X10 Clear plastic locking thermostat cover prevents unauthorized access to thermostat. Cover for
use with programmable thermostats. Outside dimensions: 7
1
/
4
″ x 9
3
/
4
″ x 3
3
/
8
″. 1 per pack
Replacement
Filters
N/A AIR-FILTER-10PK Replacement air filters in package of 10
Energy
Management
52C,P-24SI EM-KIT Allows unit to be turned on and off from a remote location (includes freeze guard protection)
Locking Security
Control Door
52C,P-23SI SECURITY-DOOR Key-locking security door to prevent access to heating and cooling controls
Lateral Duct Kit 52C,P-25SI LATERAL-DUCT Ductwork to allow one unit to heat and cool two rooms (plenum plus extension duct and registers)
Power Vent
Retrofit Kit
52C,P-32SI PWR-VENT-DOOR230 Power vent with automatic door that opens and closes when the fan turns on and off (230V).
PWR-VENT-DOOR265 Power vent with automatic door that opens and closes when the fan turns on and off (265V).
Air/Curtain
Deflector
52C,P-9SI DEFLECTOR-1PK Lateral air deflector, with individually adjustable louvers, to enhance air circulation, 1 per pack
52C,P-21SI CURTDFL-52CP-1PK Curtain deflector for 52C and 52P models — prevents curtains from blowing into
discharge air stream. 1 per pack.
NOTE: Curtain deflector for previous models are also available. Contact Carrier Representative.
Touch-Up Paint N/A CARRIER-TOUCH-UP Touch up paint for repainting scratches or chips.
