PERFORMANCE AND ELECTRICAL DATA
MODEL 52MQ (230/208 -- 1--60)
MODEL
NUMBER
52MQ
CAPACITY
EER COP
VOLTAGE
RANGE
COOLING
Cooling
Heating
AMPS WATTS
Rev. Cyc. Electic
U 0 7 --- --- --- 3 --- ---
SEE POWER
CORD
SELECTION
GUIDE BELOW
--- ---
187 --- 253
--- ---
U 0 9 --- --- --- 3 8800 / 9000 8300 / 8350 10.5 / 10.5 3.4 / 3.3 4.1 / 3.9 840 / 860
U 1 2 --- --- --- 3 12000 / 12000 10700 / 10900 11.1 / 11 .1 3.4 / 3.3 5.1 / 4.8 1080 / 1090
U 1 5 --- --- --- 3 --- --- --- --- --- ---
MODEL
NUMBER
52MQ
POWER
FACTOR
(%)
FAN MOTOR
R --- 2 2
CHARGE
(OZ)
DEHUM.
(Pint/Hr)
SENSIBLE
HEAT
FACTOR
APPROX.
CHASSIS
SHIP WT.
(lb)
Indoor
Motor
HP
Indoor
Motor
Full
Load
Amps
Indoor CFM
Out-
door
Motor
HP
Outdoor
Motor
Full Load
Amps
Low Med High
U 0 7 --- --- --- 3 --- --- --- --- --- --- --- --- --- --- --- 125
U 0 9 --- --- --- 3 100 0.029 0.2 270 320 350 0.088 0.6 28.9 2.1 0.76 125
U 1 2 --- --- --- 3 100 0.029 0.2 280 320 350 0.088 0.6 36.7 3.7 0.68 140
U 1 5 --- --- --- 3 --- --- --- --- --- --- --- --- --- --- --- 150
LEGEND
EER — Energy Ef f iciency Ratio
* Rated in accordance with ARI Standard 380-93.
† Coefficient of Performance (COP) at 47 F ou tdoor ambient temperature.
} Fan motor indoor CFM (LO/HI) shown for 230-1-60 units.
POWER CORD SELECTION GUIDE
52M PTACs are not individually equipped with a power cord, so one must be ordered separately
based on the voltage and ampeage of your electrical circuit. If the unit is to be plugged into a
receptacle, then a line cord connection kit needs to be selected. If it will be permanently connnected,
a hardwire connection must be used.
Model No. Voltage
RecepTacle
Ty pe
Heating
(BTUH)
Heater
(Kw)
Input Power
Current
(Amps)
Branch Circiut
Full Amps
PWRCORD---230V ---15A
208/230V
15 amp /250 5631 / 6949 2 1650 / 2036 11.3 15
PWRCORD---230V ---20A 20 amp /250 8556 / 10393 3 2507/ 3045 16.7 20
P W R C OR D --- 2 3 0 --- 3 0 A 30 amp /250 13778 / 16990 5 4037 / 4978 27.1 30
RECEPTACLE AND FUSE TYPES
UNIT NAMEPLATE VOLTAGE 230/208
OUTLET RATED VOLTS/AMPS 250/15 250/20 250/30
OUTLET BLADE CONFIGURATION
RECEPTACLE TYPE A B C
NEMA CONFIGURATION 6 --- 1 5 R 6 --- 2 0 R 6 --- 3 0 R
TIMEDEALYFUSEORHACRCIRCUITBREAKER(AMPS) 15 20* 30
LEGEND
HACR ---
Heating, Air Conditioning, and Refrigeration
NEMA --- National Electrical Manufacturers Association
* May be used for 15---amp applications if fu sed for 15 amps.
New York City Department of Buildings, Material
and Equipment Acceptance — MEA #------ ---- --
52M
