2.3 ELECTRICAL DAT A
a. Circuit Breaker
CB-1 Trips at 29 amps
CB-2 (50 amp) Trips at 62.5 amps
CB-2 (70 amp) Trips at 87.5 amps
b. Compressor
Motor
Full Load Amps (FLA) 13 amps @ 460 VAC
c. Condens er Fan
Motor
380 VAC, Single Phase,
50 Hz
460 VAC, Single Phase,
60 Hz
Full Load Amps 1.3 amps 1.6 amps
Horsepower 0.43 hp 0.75 hp
Rotations Per Minute 1425 rpm 1725 rpm
Voltage and Frequency 360 - 460 VAC +/- 2.5 Hz 400 - 500 VAC +/- 2.5 Hz
Bearing Lubrication Factory lubricated, additional grease not required.
Rotation Counter-clockwise when viewed from shaft end.
d. Evaporator Coil
Heaters
Number of Heaters 6
Rating 750 watts +5/-10% each @ 230 VAC
Resistance (cold) 66.8 to 77.2 ohms @ 20C (68F)
Type Sheath
e. Single Phase
Evaporator Fan
Motor(s)
380 VAC/50 Hz 460 VAC/60 Hz
Full Load Amps
High Speed
1.6 1.9
Full Load Amps
Low Speed
0.8 1.0
Nominal Horsepower
High Speed
0.49 0.84
Nominal Horsepower
Low Speed
0.09 0.11
Rotations Per Minute
High Speed
2850 rpm 3450 rpm
Rotations Per Minute
Low Speed
1425 rpm 1725 rpm
V oltage and Frequency 360 - 460 VAC +/- 1.25 Hz 400 - 500 VAC +/- 1.5 Hz
Bearing Lubrication Factory lubricated, additional grease not required
Rotation CW when viewed from shaft end
f. Three--Phase
Evaporator Fan
Motor(s)
380 VAC/50 Hz 460 VAC/60 Hz
Full Load Amps
High Speed
1.0 1.2
Full Load Amps
Low Speed
0.6 0.6
Nominal Horsepower
High Speed
0.49 0.84
Nominal Horsepower
Low Speed
0.06 0.11
Rotations Per Minute
High Speed
2850 rpm 3450 rpm
Rotations Per Minute
Low Speed
1425 rpm 1725 rpm
V oltage and Frequency 360 - 460 VAC +/- 1.25 Hz 400 - 500 VAC +/- 1.5 Hz
Bearing Lubrication Factory lubricated, additional grease not required
Rotation CW when viewed from shaft end
