PROGRAMMING QUICK REFERENCE
Program
1. Press SET TIME/TEMP SCHEDULES to enter program mode.
2. Select desired zone, using zone select dial.
3. Press ADVANCE TIME/DAY to select weekly period to program.
4. Press SELECT MIN/HR/DAY to program selected daily period.
5. Press ADVANCE TIME/DAY to change time for selected period.
6. Adjust temperature setpoints for selected period.
7. Repeat steps 4–6 to program remaining periods in daily schedule.
8. Repeat steps 3–7 to program remaining weekly periods.
9. Repeat steps 2–8 to program remaining zones.
10. Press SET TIME/TEMP SCHEDULES at any time to exit program mode.
Time Set
1. Press SELECT MIN/HR/DAY to enter time set mode.
2. Press ADVANCE TIME/DAY to change minutes.
3. Repeat steps 1–2 to set hrs/days or exit.
Hold
Press HOLD TEMPERATURES to retain current temperature setpoints.
