22
Table 12 Configuration Mode and Sub-Mode Directory (cont)
SUB-
MODE
KEYPAD
ENTRY
ITEM DISPLAY
ITEM
EXPANSION
COMMENT
OPT1 FLUD X COOLER FLUID Default: Water
Water
Medium Temperature Brine
Low Temperature Brine (30HX only)
MLVS YES/NO MIN LOAD VALVE SELCT Minimum Load Valve
HPCT X HEAD PRESS CONTROL TYPE No Control
Air Cooled (30GXN,R, 30HXA default)
Water Cooled (30HXC default)
Common Cond (30HXA Common Condenser)
Ind Cond (30HXA Independent Condenser)
VHPT X VAR HEAD PRESSURE SELECT None (30HX, 30GX No Motormaster)
4-20 mA (2-10 vdc)(30GX with Motormaster)
0-20 mA (0-10 vdc)
20-0 mA (10-0 vdc)
PRTS YES/NO PRESSURE TRANSDUCERS Default: Yes
CPC ON/OFF COOLER PUMP CONTROL Default: Off
CNP.I ON/OFF CONDENSER PUMP INTERLOCK Default: Off
(Does not require condenser pump control)
CNPC X CONDENSER PUMP CONTROL Default: No Control
No Control
On when occupied
On with compressor(s)
CWT.S YES/NO CONDENSER FLUID SENSORS Default: No
EMM YES/NO EMM MODULE INSTALLED
OPT2 CTRL X CONTROL METHOD Default: Switch
Switch = Enable/Off/Remote Contact
7 Day Occ = 7 Day Schedule
Occupancy = CCN Occupancy
CCN = CCN Control
CCNA XXX CCN ADDRESS Default: 1
Range: 1 to 239
CCNB XXX CCN BUS NUMBER Default: 0
Range: 0 to 239
BAUD X CCN BAUD RATE Default: 9600
2400
4800
9600
19,200
38,400
LOAD X LOADING SEQUENCE SELECT Default: Equal
Equal
Staged
LLCS X LEAD/LAG SEQUENCE SELECT Default: Automatic
Automatic
Circuit A Leads
Circuit B Leads
CP.SQ X COMPRESSOR SEQUENCE Default: Automatic
Automatic
Compressor 1 Leads
Compressor 2 Leads
LCWT XX.X ∆F HIGH LCW ALERT LIMIT Default: 60
Range: 2 to 60 F
DELY XX MINUTES OFF TIME Default: 0 Minutes
Range: 0 to 15 Minutes
CLS.C ENBL/DSBL CLOSE CONTROL SELECT Default: Disable
ICE.M ENBL/DSBL ICE MODE ENABLE Default: Disable
C.UNB XX % CURRENT UNBALANCE SETPOINT Default: 15%
Range: 10 to 25%
NO.FL ENBL/DSBL ENABLE NO FLOW DETECTION Default: Enable
W.MSG ENBL/DSBL WINTERIZE ALERT CONFIG Default: Enable
ALR.C X ALARM RELAY USAGE Default: Alerts + Alarms
Alerts + Alarms
Alarms Only
Off
ENTER
ENTER
To Next Page
