Carrier Edge TP-PHP01-A User Manual

44
ADVANCED PROGRAMMING OPTIONS
Changing the number of programming periods
Your thermostat is preset with four time periods. You can change this to two. Here’s
how to change the number of periods in the day.
1. Open the door.
2. Press and hold the buttons underneath the heat and
cool setpoints simultaneously (the two bottom buttons
on the right) until the screen displays the reset reminders
and 01 in the lower right corner.
3. Press the up arrow button until 01 changes to 06 with 4
(time periods) next to it.
4. Press the rightmost lower button then press the up ar -
row button until the screen displays 2.
5. Press the done button.
6. Close the door.

Carrier Edge TP-PHP01-A Specifications

General

Brand	Carrier
Model	Edge TP-PHP01-A
Category	Thermostat
Language	English
