Carrier Edge TP-PHP01-A User Manual

25
PROGRAMMING THE THERMOSTAT
10. Continue to repeat step 8, then steps 4 through 7 to pro-
gram remaining days.
11. Press the done button on the right when you’ve com-
pleted the process.
12. Close the door.
Using the programmable fan
When you use the instructions on page 45 in the Advanced Programming Options
section to turn on the programmable fan feature, you can program the fan selection
to “auto” or “on” for each of the program schedule periods. When scheduling and
setting your program periods, simply press the fan button at the top to select auto
or on for that period. You can make this change in as many days and time periods
as desired.

Carrier Edge TP-PHP01-A Specifications

General

Type	Programmable Thermostat
Connectivity	Wi-Fi
Display	Touchscreen
Power Source	24VAC
Voice Control	Amazon Alexa, Google Assistant
Stages	Up to 2 heat/2 cool
Programming	7-day programmable
Humidity Control	Yes
Temperature Range	45°F to 99°F
Weight	0.5 lbs
