Carrier Edge TP-PHP01-A User Manual

7
BUTTON IDENTIFICATION
a. SET Enters the programming schedule, adjusts the clock,
changes calendar, etc.
b. SCHEDULE Choose follow schedule, hold, or vacation
c. FAN Selects whether the fan operates continuously (on) or
only when needed for heating or cooling (auto)
d. MODE Selects whether thermostat is set for heating,
cooling, emergency heat, or auto (heat and cool as
needed), or off
e. DONE Saves settings when completing a set- up or
programming step
f. UP Adjusts the currently chosen value (temperature,
clock, calendar, etc.)
g. DOWN Adjusts the currently chosen value (temperature,
clock, calendar, etc.)
h. “SOFT” BUTTON Selects the on-screen indicator directly above the
button for adjustment
i. “SOFT” BUTTON Selects the on-screen indicator directly above the
button for adjustment
j. “SOFT” BUTTON Selects the on-screen indicator directly above the
button for adjustment
k. “SOFT” BUTTON Selects the on-screen indicator directly above the
button for adjustment
l. “SOFT” BUTTON Selects the on-screen indicator directly above the
button for adjustment
m. “SOFT” BUTTON Selects the on-screen indicator directly above the
button for adjustment

Carrier Edge TP-PHP01-A Specifications

General

Brand	Carrier
Model	Edge TP-PHP01-A
Category	Thermostat
Language	English
