Carrier FV4C User Manual

15
Table 3 – FV4C Fan Coil Airflow Delivery (CFM) in Cooling Mode
OPERATING MODE
UNIT
SIZE
OUTDOOR
UNIT
CAPACITY
SINGLE—SPEED
APPLICATION
TWO—SPEED APPLICATION FAN ONLY
Nominal
A/C
Cooling
A/C
Cooling
Dehumidity
High Speed Low Speed
Lo Med High
Nominal
A/C
Cooling
A/C
Cooling
Dehumidity
Nominal
A/C
Cooling
A/C
Cooling
Dehumidity
002
018 525 420 — — — — 350 420 525
024 700 560 700 560 560 450 350 560 700
030 875 700 — — — — 440 700 875
036 1050 840 1050 840 840 670 525 840 1050
003
024 700 560 700 560 560 450 415 560 700
030 875 700 — — — — 440 700 875
036 1050 840 1050 840 840 670 525 840 1050
042 1225 980 — — — — 610 980 1225
005
030 875 700 — — — — 440 700 875
036 1050 840 1050 840 840 670 525 840 1050
042 1225 980 — — — — 610 980 1225
048 1400 1120 1400 1120 1120 895 700 1120 1400
006
036 1050 840 1050 840 840 670 540 840 1050
042 1225 980 — — — — 610 980 1225
048 1400 1120 1400 1120 1120 895 700 1120 1400
060 1750 1400 1750 1400 1400 1120 875 1400 1750
NOTES:
1. The above airflows resul t with the AC, HP C FM ADJUST select jumper set on NOM.
2. Air flow can be adjusted +15% or ---10% by selecting HI or LO respectively for all modes except fan on ly.
3. Dry coil at 230 volts and with 10KW heater and filter installed.
4. Airflows shown are at standard air conditions.
Table 4 – FV4C Fan Coil Airflow Delivery (CFM) in Heat Pump Only Heating Mode
OPERATING MODE
UNIT
SIZE
OUTDOOR
UNIT
CAPACITY
SINGLE—SPEED
APPLICATION
TWO—SPEED APPLICATION FAN ONLY
Heat Pump
Comfort
Heat Pump
Efficiency
High Speed Low Speed
Lo Med High
Heat Pump
Comfort
Heat Pump
Efficiency
Heat Pump
Comfort
Heat Pump
Efficiency
002
018 470 525 — — — — 350 380 470
024 630 700 630 700 505 560 350 505 630
030 785 875 — — — — 390 630 785
036 945 1050 945 1050 755 840 470 755 945
003
024 630 700 630 700 415 560 415 505 630
030 785 875 — — — — 415 630 785
036 945 1050 945 1050 755 840 470 755 945
042 1100 1225 — — — — 550 880 1100
005
030 785 875 — — — — 425 630 785
036 945 1050 945 1050 755 840 470 755 945
042 1100 1225 — — — — 550 880 1100
048 1260 1400 1260 1400 1010 1120 630 1010 1260
006
036 945 1050 945 1050 755 840 540 755 945
042 1100 1225 — — — — 550 880 1100
048 1260 1400 1260 1400 1010 1120 630 1010 1260
060 1575 1750 1575 1750 1260 1400 785 1260 1575
NOTES:
1. The above airflows resul t with the AC, HP C FM ADJUST select jumper set on NOM.
2. Air flow can be adjusted +15% or ---10% by selecting HI or LO respectively for all modes except fan on ly.
3. Dry coil at 230 volts and with 10KW heater and filter installed.
4. Airflows shown are at standard air conditions.
FV4C

Carrier FV4C Specifications

General

Refrigerant	R-410A
Product Type	Air Conditioner
Model	FV4C
Efficiency	High
Stages	Variable Speed
Configuration	Vertical or Horizontal
Warranty	10-year parts limited warranty
