Carrier Infinity Control - Page 4

4
A03186
Fig. 4 -- Recessed Mount Backplate
A03187
Fig. 5 -- Surface Mount Backplate
A04017
Fig. 6 -- Thin Decorative Backplate
Recessed Mount
Interlocking Tabs (4)
Recessed terminal
block in wall 1
1
/
2
" (38.1 mm)
wide by 2
1
/
8
" (54 mm) high
A07150
Fig. 7 -- Recessed Mount Assembly
Surface Mount
Backplate to wall
Interlocking Tabs (4)
A03191
Fig. 8 -- Surface Mount Assembly
A03188
Fig. 9 -- Large Decorative Backplate
A03192
Fig. 10 -- Decorative Backplate Assembly
CCUIZ01 -- B
