LenelS2 Readers - 5000 Series
Standard 13.56 MHz/125 kHz SF/2F
- Technical specifications
Operating frequency 125 kHz & 13.56 MHz.
Reading technologies
Electromarine EM4200, HID® Proximity, MIFARE CSN 4 byte, MIFARE CSN 7 byte,
MIFARE Random UID, MIFARE Classic, MIFARE Plus, MIFARE DESFire 0.6, MIFARE
DESFire EV1, MIFARE DESFire EV2 and iCLASS UID*. Also supports other ISO
14443 A/B** compatible cards. * iCLASS cards need to support ISO1443 B.
**Not all ISO14443 B cards have been implemented in the reader, please contact
LenelS2 for more details on current status. MIFARE is a registered trademark of NXP
B.V. and is used under license.
Secure Access Module
(SAM):
MIFARE SAM AV2, external SIM card
connection slot.
Communication protocols
Wiegand, OSDP 1, OSDP 2 (including Secure channel), Supervised F2/F
RS232 and RS485.
Reading output format 24 to 1024 (excluding parity bits)
Keypad output format
Wiegand 4 bit, Wiegand 8 bit (Dorado), Wiegand 26 bit, OSDP ASCII format.
F/2F Keypad format.
Keypad
12 digit keypad in 4 rows of 3 keys in each row with configurable
backlight in blue color. Control features On/Off/Auto indicators.
Light itensity can be adjusted.
Indicators LED, Green, Red and Yellow. Backlight in blue color. Buzzer.
Power supply 9 to 30 VDC
Current consumption
24 VDC idle mode with heater inactive 45 mA**
12 VDC, idle mode with heater inactive 90 mA**
**Current consumption differs depending on functionality used
and can also be limited in the reader configuration.
Input/Output
4 input for LED- and buzzer control and 3 configurable General Purpose
Input/Output (GPI/O). The GPI/O’s are push/pull type which provides 5.0VDC
as output when “high” on each respective GPI/O connection pin.
Tamper alarm
Built-in mechanical tamperswitch which allows for
indication both break off protection and opening of the reader.
Operating temperature
-40° to +70°C
When installing readers in environments with extreme heat
(above +50°C) it is recommended to utilize the climate protection
LNL-R50000-WRW which provides additional shading to the reader.
Heater Thermostat controlled embedded heater.
Operating humidity
0 to 95% RHNC
(Relative Humidity No Condensation)
IP rating IP65
Dimension (W x H x D) 79 x 109 x 25
Configuration method
Configuration card, reader tool software or factory configured readers.
Compliances
4
Lenel Readers - 5000 Series
Standard 13,56MHz/125kHz SF/2F
- Technical specications
Operating frequency 125kHz & 13,56MHz.
Reading technologies
Electromarine EM4200, HID® Proximity, MIFARE CSN 4 byte,
MIFARE CSN 7 byte, MIFARE Classic, MIFARE Plus, MIFARE DESFire 0.6 and
MIFARE DESFire EV1. Also supports other ISO 14443 A/B* compatible cards.
*Not all ISO14443 B cards have been implemented in the reader, please contact
Lenel for more details on current status. MIFARE is a registered trademark of
NXP B.V. and is used under license.
Secure Access Module
(SAM):
MIFARE SAM AV2, external SIM card
connection slot.
Communication protocols
Wiegand, OSDP 1, OSDP 2 (including Secure channel), Supervised F2/F
RS232 and RS485.
Reading output format 24-1024 (excluding parity bits)
Keypad output format
Wiegand 4bit, Wiegand 8bit (Dorado), Wiegand 26bit, OSDP ASCII format.
F/2F Keypad format.
Keypad
12 digit keypad in 4 rows of 3 keys in each row with congurable
backlight in blue color. Control features On/O/Auto indicators.
Light itensity can be adjusted.
Indicators LED, Green, Red and Yellow. Backlight in blue color. Buzzer.
Power supply 9 – 30VDC
Current consumption
24VDC idle mode with heater inactive 45 mA**
12VDC, idle mode with heater inactive 90 mA**
**Current consumption diers depending on functionality used
and can also be limited in the reader conguration.
Input/Output
4 input for LED- and buzzer control and 3 congurable General Purpose
Input/Output (GPI/O). The GPI/O’s are push/pull type which provides 5.0VDC
as output when “high” on each respective GPI/O connection pin.
Tamper alarm
Built-in mechanical tamperswitch which allows for
indication both break o protection and opening of the reader.
Operating temperature
–40° – +70°C
When installing readers in environments with extreme heat
(above + 50*C) it is recommended to utilize the climate protection
LNL-R50000-WRW which provides additional shading to the reader.
Heater Thermostat controlled embedded heater.
Operating humidity
0 – 95% RHNC
(Relative Humidity No Condensation)
Ingress Protection
Classication
IP 65
Housing dimension L=109mm, H=25mm, W=79mm
Conguration Methods Conguration card, reader tool software or factory congured readers.
Compliances
