Carrier Performance 50VR-A - Page 15

15
A13151
Fig. 12 -- Defrost Control Board
COMPRESSOR
ACCUMULATOR
OUTDOOR COIL
INDOOR COIL
LCS
LEGEND
HPS – High Pressure Switch
LCS – Loss of Charge Switch
Accurater
®
Metering De vice
Arrow indicates direction of flo w
Position
HP S
TXV in Bypass
Metering
Position
C03012
Fig. 13 -- Typical Heat Pump Operation, Heating Mode
COMPRESSOR
ACCUMULATOR
OUTDOOR COIL
INDOOR COIL
LCS
LEGEND
HPS – High Pressure Switch
LCS – Loss of Charge Switch
Accurater
®
Metering De vice
Arrow indicates direction of flo w
TXV in Metering
Position
Bypass
Position
HP S
C03011
Fig. 14 -- Typical Heat Pump Operation, Cooling Mode
50VR
