Table 5 – Dry Coil Air Delivery* -- Horizontal and Downflow Discharge -- Unit 50VR----24--60 Without Advanced Dehumidification (AD) FIOP 208/230 VAC Models
UNIT
MOTOR
SPEED
WIRE
COLOR
EXTERNAL STATIC PRESSURE (IN. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
C24
Low¹ Blue
CFM 777 692 583 465 318 --- --- --- --- ---
BHP 0.09 0.10 0.10 0.11 0.12 --- --- --- --- ---
Med-Low Pink
CFM 877 779 698 598 519 410 --- --- --- ---
BHP 0.12 0.12 0.13 0.14 0.15 0.15 --- --- --- ---
Medium² Red
CFM 904 841 769 705 628 522 372 --- --- ---
BHP 0.16 0.17 0.17 0.18 0.19 0.19 0.20 --- --- ---
Med-High Orange
CFM 1229 1171 1105 1049 980 913 838 775 679 516
BHP 0.28 0.30 0.30 0.31 0.32 0.33 0.33 0.34 0.34 0.33
High Black
CFM 1291 1206 1142 1081 1017 951 888 823 753 668
BHP 0.31 0.32 0.33 0.34 0.34 0.35 0.36 0.36 0.37 0.37
C30
Low Blue
CFM 777 692 583 465 318 --- --- --- --- ---
BHP 0.09 0.10 0.10 0.11 0.12 --- --- --- --- ---
Med-Low¹ Pink
CFM 831 765 670 586 466 299 --- --- --- ---
BHP 0.11 0.12 0.12 0.13 0.13 0.14 --- --- --- ---
Medium² Red
CFM 1139 1069 1012 937 870 786 724 626 512 381
BHP 0.22 0.23 0.24 0.24 0.25 0.26 0.26 0.27 0.27 0.28
Med-High Orange
CFM 1229 1171 1105 1049 980 913 838 775 679 516
BHP 0.28 0.30 0.30 0.31 0.32 0.33 0.33 0.34 0.34 0.33
High Black
CFM 1531 1460 1382 1301 1209 1114 1003 890 764 629
BHP 0.53 0.52 0.50 0.48 0.46 0.44 0.42 0.40 0.37 0.35
A36
Low Blue
CFM 1097 971 823 747 669 636 558 513 456 412
BHP 0.12 0.11 0.10 0.11 0.12 0.13 0.13 0.14 0.15 0.16
Med-Low¹ Pink
CFM 934 864 810 745 698 649 571 525 486 428
BHP 0.10 0.10 0.11 0.12 0.13 0.14 0.14 0.15 0.16 0.17
Medium² Red
CFM 1251 1198 1149 1104 1066 1017 970 932 892 839
BHP 0.19 0.21 0.21 0.23 0.24 0.25 0.26 0.27 0.28 0.29
Med-High Orange
CFM 1451 1415 1372 1327 1287 1249 1212 1168 1130 1094
BHP 0.29 0.30 0.31 0.32 248.59 0.35 0.36 0.37 0.38 0.39
High Black
CFM 1466 1423 1384 1343 1308 1263 1219 1183 1145 1106
BHP 0.30 0.31 0.33 0.34 0.35 0.36 0.37 0.38 0.40 0.41
