Table 5 -- Dry Coil Air Deliv ery* -- Horizontal and Downflow Discharge (CONT)-- Unit 5 0VR----24--60 Without Adva nced Dehumidification (AD) FIOP 208/230 VAC Model
UNIT
MOTOR
SPEED
WIRE
COLOR
EXTERNAL STATIC PRESSURE (IN. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
A42
Low Blue
CFM 1097 971 823 747 669 636 558 513 456 412
BHP 0.12 0.11 0.10 0.11 0.12 0.13 0.13 0.14 0.15 0.16
Med-Low¹ Pink
CFM 1076 1026 972 918 872 827 771 714 666 611
BHP 0.13 0.14 0.15 0.15 0.17 0.18 0.18 0.20 0.21 0.22
Medium Red
CFM 1251 1198 1149 1104 1066 1017 970 932 892 839
BHP 0.19 0.21 0.21 0.23 0.24 0.25 0.26 0.27 0.28 0.29
Med-High² Orange
CFM 1451 1415 1372 1327 1287 1249 1212 1168 1130 1094
BHP 0.29 0.30 0.31 0.32 248.59 0.35 0.36 0.37 0.38 0.39
High Black
CFM 1633 1590 1552 1518 1483 1444 1406 1372 1340 1303
BHP 0.41 0.43 0.44 0.45 0.47 0.48 0.49 0.50 0.51 0.53
A48
Low¹ Blue
CFM 1271 1229 1177 1121 1066 1027 974 942 887 839
BHP 0.19 0.20 0.21 0.23 0.24 0.25 0.26 0.27 0.28 0.29
Med-Low Pink
CFM 1340 1299 1240 1191 1139 1091 1050 1001 952 895
BHP 0.22 0.23 0.24 0.25 0.26 0.28 0.29 0.30 0.31 0.32
Medium² Red
CFM 1686 1650 1617 1576 1544 1503 1468 1433 1393 1356
BHP 0.42 0.44 0.45 0.46 0.48 0.49 0.51 0.52 0.53 0.55
Med-High Orange
CFM 1854 1837 1781 1784 1720 1698 1655 1625 1578 1532
BHP 0.56 0.57 0.60 0.59 0.62 0.63 0.64 0.66 0.67 0.67
High Black
CFM 1934 1900 1855 1815 1778 1737 1695 1656 1606 1528
BHP 0.59 0.61 0.62 0.64 0.65 0.67 0.68 0.70 0.70 0.68
A60
Low Blue
CFM 1182 1137 1102 1053 1012 966 920 868 830 783
BHP 0.21 0.22 0.23 0.24 0.25 0.26 0.27 0.28 0.30 0.31
Med-Low
1
Pink
CFM 1454 1405 1364 1316 1281 1234 1198 1147 1105 1056
BHP 0.34 0.35 0.36 0.37 0.38 0.40 0.41 0.42 0.43 0.45
Medium
2
Red
CFM 1818 1770 1731 1693 1657 1621 1579 1546 1505 1436
BHP 0.56 0.57 0.59 0.60 0.62 0.63 0.64 0.66 0.67 0.66
Med-High Orange
CFM 1881 1849 1818 1793 1763 1729 1679 1610 1523 1479
BHP 0.67 0.69 0.70 0.71 0.72 0.73 0.73 0.71 0.68 0.65
High Black
CFM 2138 2084 2025 1967 1893 1829 1754 1678 1591 1475
BHP 0.98 0.95 0.93 0.90 0.86 0.84 0.80 0.76 0.74 0.68
* Air delivery values are without air filter and are for dry coil (See Wet Coil Pressure Drop table). 1
Factory---shipped low stage cooling speed.
2
Factory---shipped high stage cooling speed.
Note: Deduct field---supplied ai r filter pressure drop and wet coil pressure drop to obtain external static pressure available for ducting.
Shaded areas indicate acceptable D ehum. Speeds (Dehu m. Mode is High Stage Only, 208/230 VAC Models Only).
50VR
