Table 6 – Dry Coil Air Delivery* -- Horizontal and Downflow Discharge -- Unit 50VR-- (A,C)24--60 With Advanced Dehumidification (AD) FIOP 208/230 VAC Model
UNIT
SIZE
CFM ADJUST
PIN SELECT
LO PIN NOM PIN HI PIN
EXTERNAL STATIC
PRESSURE RANGE
0.0 --- 0.39 0.4 --- 0.69 0.7 --- 1.0 0.0 --- 0.39 0.4 --- 0.69 0.7 --- 1.0 0.0 --- 0.39 0.4 --- 0.69 0.7 --- 1.0
C24
HIGH STAGE
COOLING 770 795 790 855 885 875 940 975 965
COOLING WITH DEHUMIDIFY 610 615 570 675 685 635 745 755 700
LOW STAGE
COOLING 610 610 570 675 680 635 745 750 700
COOLING WITH DEHUMIDIFY 475 470 360 530 520 401 585 570 440
C30
HIGH STAGE
COOLING 905 935 935 1005 1040 1040 1105 1145 1145
COOLING WITH DEHUMIDIFY 715 740 725 795 820 803 875 900 885
LOW STAGE
COOLING 715 740 730 795 820 810 875 900 890
COOLING WITH DEHUMIDIFY 555 555 485 615 615 540 675 675 595
A36
HIGH STAGE
COOLING 1060 1100 1095 1175 1220 1215 1295 1340 1335
COOLING WITH DEHUMIDIFY 845 880 875 940 975 970 1035 1075 1065
LOW STAGE
COOLING 835 850 845 930 945 940 1025 1040 1035
COOLING WITH DEHUMIDIFY 675 685 670 750 760 745 825 835 820
A42
HIGH STAGE
COOLING 1240 1265 1275 1375 1405 1414 1515 1545 1555
COOLING WITH DEHUMIDIFY 1010 1040 1015 1120 1155 1125 1230 1270 1240
LOW STAGE
COOLING 970 975 965 1075 1085 1070 1185 1195 1175
COOLING WITH DEHUMIDIFY 785 790 790 870 880 875 955 970 965
A48
HIGH STAGE
COOLING 1445 1450 1445 1605 1610 1605 1765 1770 1765
COOLING WITH DEHUMIDIFY 1155 1170 1255 1285 1300 1395 1415 1430 1535
LOW STAGE
COOLING 1095 1105 1095 1215 1225 1215 1335 1350 1335
COOLING WITH DEHUMIDIFY 880 890 875 975 990 970 1075 1090 1065
A60
HIGH STAGE
COOLING 1565 1570 1555 1740 1745 1725 1915 1920 1900
COOLING WITH DEHUMIDIFY 1270 1280 1280 1410 1424 1420 1550 1565 1560
LOW STAGE
COOLING 1250 1265 1260 1390 1405 1400 1530 1545 1540
COOLING WITH DEHUMIDIFY 1015 1015 1015 1125 1130 1125 1240 1245 1240
NOTE: Field ---supplied air filter and wet coil pressure drop will minimally affect air delivery values.
Continuous Fan CFM is 50% of High Stage Cooling Airflow.
