PERFORMANCE DATA (CONT)
060 Coolin g Extended Performance Table
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM /
BF
EWB
Capacity MBtuh
To t a l
Sys
KW
Capacity MBtuh
To t a l
Sys
KW
Capacity MBtuh
To t a l
Sys
KW
Capacity MBtuh
To t a l
Sys
KW
Capacity MBtuh
To t a l
Sys
KW
Capacity MBtuh
To t a l
Sys
KW
To t a l Sens To t al Sens To t al Sens To t al Sens To t al Sens To ta l Sens
1750 /
0.07
57 63.53 63.53 3.78 58.78 58.78 4.29 53.97 53.97 4.86 49.09 49.09 5.49 44.01 44.01 6.19 42.42 42.42 6.41
62 65.04 51.03 3.79 59.74 50.40 4.30 54.44 49.51 4.86 49.15 49.15 5.50 44.01 44.01 6.19 38.66 38.66 6.95
63* 65.92 41.28 3.80 60.47 40.65 4.31 54.99 39.84 4.87 49.48 38.85 5.50 43.83 37.60 6.19 42.07 38.16 6.40
67 70.86 42.85 3.85 64.96 42.22 4.35 59.00 41.40 4.92 52.98 40.40 5.54 46.84 39.11 6.23 40.50 37.40 6.98
72 77.33 34.48 3.90 70.80 33.73 4.41 64.19 32.79 4.98 57.55 31.67 5.60 50.77 30.29 6.29 43.78 28.58 7.03
2000 /
0.08
57 66.05 66.05 3.88 61.00 61.00 4.40 55.88 55.88 4.97 50.65 50.65 5.60 45.26 45.26 6.30 39.58 39.58 7.06
62 66.61 54.49 3.89 61.13 61.13 4.40 55.88 55.88 4.97 50.66 50.66 5.60 45.25 45.25 6.30 39.57 39.57 7.06
63* 67.26 43.89 3.89 61.59 43.24 4.40 55.88 42.41 4.97 50.16 41.35 5.59 44.32 39.99 6.29 38.33 38.21 7.04
67 72.23 45.64 3.94 66.09 45.00 4.45 59.87 44.14 5.01 53.63 43.07 5.64 47.29 41.70 6.33 40.75 39.91 7.08
72 78.76 36.15 4.00 71.95 35.36 4.51 65.10 34.38 5.07 58.23 33.22 5.70 51.25 31.78 6.38 44.04 29.99 7.12
2250 /
0.09
57 68.16 68.16 3.98 62.83 62.83 4.50 57.41 57.41 5.07 51.90 51.90 5.70 46.22 46.22 6.40 40.27 40.27 7.16
62 68.17 68.17 3.98 62.83 62.83 4.50 57.41 57.41 5.07 51.90 51.90 5.71 46.22 46.22 6.40 40.27 40.27 7.16
63* 68.27 46.41 3.98 62.41 45.72 4.49 56.54 44.84 5.06 50.64 43.71 5.69 44.66 42.24 6.38 38.53 40.25 7.13
67 73.27 48.35 4.03 66.92 47.68 4.54 60.50 46.77 5.10 54.10 45.64 5.73 47.60 44.16 6.42 40.92 42.14 7.17
72 79.84 37.74 4.09 72.79 36.91 4.60 65.73 35.91 5.16 58.70 34.70 5.79 51.53 33.23 6.48 44.15 31.39 7.22
*At 75_F (23.9 _C) entering dry bulb—Tennessee Valley Authority [TVA] rating conditions; all others at 80_F (26.7 _C) entering dry bulb. See Legend and Notes.
060 Heating Extended Performance Table --10--60 (--23.3--15.6_C)
INDOOR AIR
OUTDOOR CO I L ENTERING AIR TEMPERATURES deg F
--- 1 0 0 10 20 30 40 50 60
EDB CFM
Capacity
MBtuh
Tot a l
Sys
KW
Capacity
MBtuh
Tot a l
Sys
KW
Capacity
MBtuh
Tot a l
Sys
KW
Capacity
MBtuh
Tot a l
Sys
KW
Capacity
MBtuh
Tot a l
Sys
KW
Capacity
MBtuh
Tot a l
Sys
KW
Capacity
MBtuh
Tot a l
Sys
KW
Capacity
MBtuh
Tot a l
Sys
KWTot a l Integ Tot a l Integ Total Integ Tot al Integ Tot al Integ To tal Integ Tot al Integ Tot al Integ
65
1750 21.44 19.72 3.85 27.02 24.86 3.97 32.88 30.18 4.09 39.13 35.49 4.23 46.15 40.44 4.40 54.26 54.26 4.61 63.98 63.98 4.86 74.82 74.82 5.16
2000 21.85 20.11 3.90 27.45 25.26 4.01 33.33 30.60 4.12 39.63 35.94 4.24 46.77 40.98 4.38 55.02 55.02 4.56 65.19 65.19 4.78 74.99 74.99 5.04
2250 22.24 20.46 3.97 27.85 25.63 4.06 33.75 30.98 4.15 40.07 36.34 4.26 47.32 41.46 4.39 56.12 56.12 4.56 65.29 65.29 4.75 73.80 73.80 4.99
70
1750 20.75 19.09 4.03 26.44 24.33 4.16 32.38 29.72 4.30 38.64 35.04 4.45 45.62 39.97 4.62 53.55 53.55 4.84 62.76 62.76 5.10 73.96 73.96 5.41
2000 21.17 19.48 4.09 26.88 24.73 4.20 32.84 30.14 4.32 39.14 35.50 4.45 46.18 40.46 4.60 54.29 54.29 4.79 64.31 64.31 5.02 74.39 74.39 5.29
2250 21.56 19.84 4.15 27.28 25.11 4.25 33.25 30.52 4.36 39.59 35.91 4.47 46.68 40.90 4.61 54.93 54.93 4.78 64.77 64.77 4.98 73.71 73.71 5.23
75
1750 20.00 18.40 4.22 25.80 23.74 4.36 31.83 29.21 4.51 38.15 34.60 4.68 45.07 39.49 4.86 52.71 52.71 5.07 61.83 61.83 5.35 73.09 73.09 5.68
2000 20.42 18.79 4.28 26.26 24.16 4.40 32.30 29.64 4.53 38.62 35.03 4.67 45.64 39.99 4.83 53.58 53.58 5.03 63.19 63.19 5.27 73.64 73.64 5.54
2250 20.82 19.15 4.34 26.67 24.54 4.46 32.73 30.04 4.57 39.07 35.43 4.69 46.14 40.43 4.84 54.20 54.20 5.01 64.17 64.17 5.22 73.39 73.39 5.47
50VT
To Next Page
