Carrier Performance 50VT User Manual

2
keeps the conditioned air from being affected by the outdoor
ambient temperature and provides improved indoor air quality.
(Conforms to American Society of Heating, Refrigeration and Air
Conditioning Engineers No. 62P.) The sloped drain pan minimizes
standing water in the drain. An external drain is provided.
Short--Cycling protection for the compressor is incorporated into
our defrost control board ensuring a five minute delay (+/--2
minutes) before restarting compressor after shutdown for any
reason.
TABLE OF CONTENTS
FEATURES/BENEFITS 1 --2.............................
MODEL NUMBER NOMENCLATURE 2.................
ARI C APACITIES 3...................................
PHYSICAL DATA 4...................................
OPTIONS AND ACCESSORIES 5.......................
BASE UNIT DIMENSIONS 8 --9.........................
ACCESSORY DIMENSIONS 10.........................
SELECTION PROCEDURE 11..........................
PERFORMANCE DATA 12 --19..........................
TYPICAL PIPING AND WIRING 20.....................
APPLICATION DATA 21...............................
ELECTRICAL DATA 23 --24............................
TYPICAL WIRING SCHEMATICS 25--27.................
CONTROLS 28.......................................
GUIDE SPECIFICATIONS 29 --30........................
MODEL NUMBER NOMENCLATURE
50VT
--- ---
--- --- ---
1
Typ e of U ni t
50VT --- Single Packaged
Heat Pump Unit
Nominal Cooling Capacity
024 --- 2.0 Tons
030 --- 2.5 Tons
036 --- 3.0 Tons
042 --- 3.5 Tons
048 --- 4.0 Tons
060 --- 5.0 Tons
024
N/A
Electrical Supply
3 --- 208/230---1--- 60
5 --- 208/230---3--- 60
6 --- 4 6 0 --- 3 --- 6 0
3
0
Series
Packaging
Options
AD --- Louvered Grille
BT --- AL evap, vinyl condenser
CC --- AL evap, CU condenser
CU --- CU evap & condenser
TP --- Base unit with tin plated indoor coil hairpins
TV --- TP with vinyl coating on outdoor coil
TC --- TP with AL indoor coil & CU/CU outdoor coil
See Price Page for full list of factory options.
Only used if ordering an option
LEGEND
AL --- Aluminum
CU --- Copper
N/A --- Not applicable
---
N/A
REGISTERED
ISO 9001:2000
A
s an Energy Star® Partner, Carrier
Corporation has determined that this
product meets the ENERGY STAR®
guidelines for energy efficiency.
50VT
