3.2 TIMER FUNCTION
TIMER ON/OFF - Set the amount of time after which the unit will automatically turn on/off.
TIMER
ON
NOTE:
1. When setting the TIMER ON or TIMER OFF, the time will increase by 30 minutes increments with each
press, up to 10 hours. After 10 hours and up to 24, it will increase in 1 hour increments. (For example,
press 5 times to get 2.5h, and press 21 times to get 11h,) The timer will revert to 0.0 after 24.
2. Cancel either function by setting its timer to 0.0h.
Point remote to unit and wait 1sec,
the TIMER ON will be activated.
TIMER
OFF
Press it for multiple times to set
the desired time to turn off the unit.
Point remote to unit and wait 1sec,
the TIMER OFF will be activated.
Setting TIMER ON & OFF (example).
Current
time 1PM
2:00PM 3:00PM
4PM 5PM
6PM
Timer starts
Unit turns
ON
Unit turns
OFF
2.5 hours later
5 hours later
3:30PM
Example: If current timer is 1:00PM,
to set the timer as above steps, the
unit will turn on 2.5h later (3:30PM)
and turn off at 6:00PM.
ON/OFF
M
ODE
F
AN
SHORT
CUT
TIMER ON
TIMER OF
F
TEMP
S
L
E
EP
ON/OFF
M
ODE
F
AN
SHORT
CUT
TIMER ON
TIMER OF
F
TEMP
S
L
E
EP
Press TIMER button to initiate
the ON time sequence.
Press Temp. up or down button for
for multiple times to set the desired
time to turn on the unit.
Press TIMER button to initiate
the OFF time sequence.
xn
xn
TIMER
TIMER
ON/OFF
MODE
F
AN
SHORT
CU
T
TIMER ON
TIMER OF
F
TEMP
SL
E
EP
ON/OFF
MODE
F
AN
SHORT
CUT
TI
M
E
R
O
N
TIMER OF
F
TEMP
S
L
E
EP
xn
xn
xn
TIMER
TIMER
