4–53 T-340
Table 4–8 DataCORDER Function Code Assignments
NOTE
Inapplicable Functions Display “-----”
To Access: Press the ALT. MODE key
Code Title Description
dC1 Recorder Supply Temperature Current reading of the supply recorder sensor.
dC2 Recorder Return Temperature Current reading of the return recorder sensor.
dC3-5 USDA 1, 2, 3 Temperatures Current readings of the three USDA probes.
dC6-13 Network Data Points 1-8 Current values of the network data points (as configured). Data point
1 (Code 6) is generally the humidity sensor and its value is obtained
from the controller once every minute.
dC14 Cargo Probe 4 Temperature Current reading of the cargo probe #4.
dC15-19 Future Expansion These codes are for future expansion, and are not in use at this time.
dC20-24 Temperature Sensors 1-5
Calibration
Current calibration offset values for each of the five probes: supply,
return, USDA #1, #2, and #3. These values are entered via the in-
terrogation program.
dC25 Future Expansion This code is for future expansion, and is not in use at this time.
dC26,27 S/N, Left 4, Right 4 The DataCORDER serial number consists of eight characters.
Function code dC26 contains the first four characters. Function
code dC27 contains the last four characters. (This serial number is
the same as the controller serial number.)
dC28 Minimum Days Left An approximation of the number of logging days remaining until the
DataCORDER starts to overwrite the existing data.
dC29 Days Stored
Number of days of data that are currently stored in the DataCORDER.
dC30 Date of Last Trip start
The date when a Trip Start was initiated by the user. In addition, if the
system goes without power for seven continuous days or longer, a
trip start will automatically be generated on the next AC power up.
Press and hold the ENTER key for five seconds to initiate a “Trip
Start.”
dC31 Battery Test Results Shows the current status of the optional battery pack.
PASS: Battery pack is fully charged.
FAIL: Battery pack voltage is low.
dC32 Time: Hour, Minute Current time on the real time clock (RTC) in the DataCORDER.
dC33 Date: Month, Day Current date (month and day) on the RTC in the DataCORDER.
dC34 Date: Year Current year on the RTC in the DataCORDER.
dC35 Cargo Probe 4 Calibration Current calibration value for the Cargo Probe. This value is an input
via the interrogation program.
To Next Page
